7-1 Troubleshooting Errors When Creating Screens

7-1 Troubleshooting Errors When Creating Screens
This section describes possible errors occurred when creating screens with the CX-Designer
and their countermeasures.
This section explains errors specific to the NS-Runtime. Refer to 5 Troubleshooting and
Maintenance in the NS Series Programming Manual for information on other errors.
Symptoms
Cannot resize a
screen in the screen
properties.
Cannot convert a
Project.
Cannot set the Save
Cycle for $HB/$HW
and Data Log.
Cannot save data log
setting.
Cannot save a
document table
setting.
Cannot arrange a
document display
object.
7-2
Cause
Values out of range are set for the
screen size.
Attempted to convert projects, for
which the serial port A/B is set to
the following settings, to
NSA12/15-TX01[] or NS-Runtime.
-
Host Type is other than SYSMAC-
PLC
-
Temperature Controller Unit
-
Memory Link
-
Bar code
-
Modem Connection
Attempted to convert an NS-
Runtime project with more than
50,000 records in a normal log to
an NS-series project.
Attempted to convert an NS-
Runtime project with macros
supported only by the NS-Runtime
to an NS-series project.
Attempted to convert an NS-
Runtime project into an NS-series
project using version 3.0 or lower
of the CX-Designer.
Value out of range has been set for
the Save Cycle in the system
setting dialog box.
The logging points total that have
been set in Data Log Setting Dialog
Box exceed 160,000 points.
Attempted to set an invalid path for
the document folder.
The file extension is not '.pdf'.
Attempted to create a document
display object on a frame, sheet or
pop-up screen.
Attempted to create two or more
document display objects on one
screen.
Possible Countermeasure
Set as follows.
-
NSA Series
Height: 1 to 768, Width: 1 to 1024
-O
ther than NSA Series
The size must be the same or smaller
than the maximum screen size that is
set in the System Setting Menu under
the PT Menu.
Convert a project for which serial port is
set to the PLC and the host type is set to
the SYSMAC-PLC.
Or, convert a project for which the serial
port is set to the Not used.
Change the log so that it contains less
than 50,000 records and attempt the
conversion again.
Delete macros that can be used only for
NS-Runtime and attempt the conversion
again.
Projects cannot be converted from NS-
Runtime project the NS-series projects
using version 3.0 or lower of the CX-
Designer.
Set a value to between 1 second and 24
hours for the save cycle.
Set it to 160,000 points or less.
Specify a correct path.
Specify a file which extension is '.pdf'.
Create a document display object on a
base screen.
Only one document display object can
be created on each screen.
