1-3 CX-Designer Menu List

1-3 CX-Designer Menu List

The NS-Runtime has the following pull-down menus that are different from CX-Designer's.
Menus not described here are the same as the existing CX-Designer's menus.
File Menu
There are following changes in the File Menu.
New project
Print
Data Transfer Security
• Edit Menu
There is no change in the Edit Menu.
• Find Menu
There is no change in the Find Menu.
• View Menu
There is a following change in the View Menu.
Show Touch Points
• PT Menu
There are following changes in the PT Menu.
Transfer
System Setting
Alarm/Event Setting
Data Log Setting
Document Table Setting
Screen/Sheet Properties
1-6
Item
Creates new projects. The NSA12/15-TX01[] and
the NS-Runtime are added.
Select the NS-Runtime when using the NS-
Runtime in an environment other than NSA Series.
Document Table Setting is added to the Print Item
Details.
This menu cannot be used.
Item
This menu cannot be used.
Item
When the CX-Designer and NS-Runtime is
installed in the same environment, a function to
copy project data to the NS-Runtime project
storage folder will be added.
Sets an NS-Runtime's parameter operating.
The following changes are made.
-A folder can be specified to save history data.
-Maximum screen size can be set.
Registers and modifies the alarm/event.
Setting items for the display document table are
added, which enables to show on a document
display object when an alarm occurs.
Always logging can be set up to 160,000 points.
Registers document files (PDF files) to display on
document display objects.
Setting ranges were changed as follows.
-NSA Series: 1024 x 768 dots max.
-Other than NSA Series: 3840 x 2400 dots max.
Function
Function
Function
Reference
3-1
−
−
Reference
−
Reference
6-1
3-2
4-3
4-4
4-2-2
3-4
