6-3 Transferring Data from the CX-Designer

If the CX-Designer has been installed in the NS-Runtime environment, project data edited
with the CX-Designer can be downloaded/uploaded to the NS-Runtime. Use the followings
transfer procedures.
1. Exit the NS-Runtime.
2. Display the Comms. Method Dialog Box by any of the following ways with the CX-
Designer.
- Select PT Menu - Transfer - Transfer Setting
- Select PT Menu - Transfer - Quick Transfer [To PT]. Click the Setting Button in the
displayed dialog box.
- Select PT Menu - Transfer [To PT]. Click the Setting Button in the displayed dialog box.
- Select PT Menu - Transfer - Transfer Program. Click the Comms. Method Button in
the displayed Screen Data Transfer Dialog Box.
6-3 Transferring Data from the CX-Designer
6-11
