- Page 1 Screen Designer for NS Series NS-CXDC1-V1 CX-Designer – Brand new screen Designer for NS-series PTs. Greatly reduces the effort of creating screens.
- Page 2 Work hours spent setting addresses can be greatly reduced by importing CX-Programmer Symbol Tables. The project Workspace and Output Window are used for the user interface just as with the other Support Software packaged in the CX-One. User Interface with the Utmost in Efficiency All addresses and comments can be managed using a single Symbol Table.
-
Page 3: Drag And Drop
Example of Easy Address Allocation Create a switch on the screen. Check the comment then drag-and-drop the symbol from the symbol table to the property list. Allocations for buttons and lamps can also be Drag & Drop! Drag & Drop! - Page 4 A variety of newly added functions greatly improves editing, reusing, and search functions for screens and objects. Reusing Screens and Objects Is Setting Each Object on the Screen One Troublesome. by One Is Troublesome. Easily Reuse Screens and Objects Edit Properties Screens can be easily reused between projects by dragging •...
- Page 5 Controller faceplate Completed in 15 seconds with the CX-Designer. takes minutes. The figures above are reference values based on comparisons made by OMRON. CX-Designer version 1.0 was used for the measurements. Actual figures may vary with the computer's operating environment.
- Page 6 Precaution on CX-Designer Operating System The CX-Designer will not run on Microsoft Windows 95 or on operating systems with service packs older than those given in the system requirements. If you are using Window 95 or an older service pack than given in the specifications, you must upgrade your operating system before installing the CX-Designer.
