When setting more than 42 characters for the PDF file name, the following dialog box will be
displayed. Rename the file name (Maximum of 42 characters).
In the same way, if the specified file name contains an unusable character, a dialog box asking
you to rename will be displayed.
4-2-2

Document Display

To create a document display, select the Functional Objects Menu – Document Display,
or select
Setting Items of Functional Object Properties.
This section describes setting items displayed in the document display's functional object
properties dialog box.
Item
No.
Comment
Document File
Add
Delete
e
e
e
icon.
Document number will be displayed.
Enter comments of up to 32 characters.
Set a document file for each label.
Enter a file name directly or select a file from a file selector
that is displayed by clicking
When selecting the project folder from the document position
and selecting a document file from the file selector, the
document files will be automatically copied to the project
folder.
When selecting the document folder from the document
position or when directly entering a file name, users need to
manually copy the file to the specified folder.
Adds document numbers.
Up to 5000 numbers can be added.
Among the unused numbers, the smallest number will be
added.
Deletes selected document numbers.
4-2 Document Display
Details
Button.
4-9
