Connector Locations

40-Pin GPIO
P13
SW2
USB Type-A
(P11A P12A)
Document: CTIM-00107
Revision: 0.00
ES France - Mobilité & Systèmes Embarqués
127 rue de Buzenval BP 26 - 92380 Garches
TOP VIEW
SIM Card Holder
P10
RTC
CR2032
GBE2
(P7)
Page 10 of 27
Tél. 01 47 95 99 80
Fax. 01 47 01 16 22
HDMI
P5
USB Type-A
GBE1
(P11B P12B)
Lepton
Users Guide
www.connecttech.com
CAN
P15
SW1
USB Type-C + OTG
(P6)
