5 Controlling Robot via WEB App


●The WEB app is developed for common users to control the robot in an easier way. It's convenient to use
WEB app; you may use it to wirelessly control the robot on any device with a web browser
used for testing).
●Generally Raspberry Pi will auto run `webServer.py` when booting and establish a web server in the LAN.
You may then use any other computer, mobile or tablet in the same LAN to visit the web page and control the
robot.
● How to tell whether the robot has run the `webServer.py` or not: If the WS2812-LED lights up with the
breathing effect, it means the robot has booted and runs the program automatically.
● If the program is not run when the robot is booted, try to connect Raspberry Pi via SSH, manually run
`webServer.py` with code and check the errors. Refer to the Q&A below or email us for help (before manually
running `webServer.py`, you need to end the program possibly auto run in the back end to release resources.
sudo killall python3
sudo python3 [RobotName]/server/webServer.py
●If the `webServer.py` is auto run successfully, open a web browser
address of the Raspberry Pi, with `:5000` added to the end, and go to the next step, as shown below:
192.168.3.157:5000
●If no image is displayed, try manual running `webServer.py` as described in the step above.
●If image is shown, you can control the robot to move now. You may check the description for keyboard
shortcuts `Instruction` at the bottom and control the robot based on its general functions with the keyboard.
●`Video` window shows the image captured by the robot's camera in real time.
●`Move Control` window is to control the basic movements of the robot.
●`Arm Control` control the rotation of the robot Platform Servo.
·`UP`: control the Platform Servo to turn upward.
·`DOWN`: control the Platform Servo to turn down.
●`CVFL Control` window is to control the visual line following function of the robot. Here only an overview
for the function is described; more details will be provided in the OpenCV section:
·`START`: Enable or disable the visual line following function.
·`COLOR`: Switch between white and black line following. By default the robot follows white lines; click
the button to switch to black line following.
·The line following function analyzes two pixels in parallel and utilizes the information detected; the
positions of these two pixels are `L1` and `L2`.
·`SP` is the threshold of the turning command based on the visual analysis results. A bigger `SP` value
means a big deviation; though a particularly small `SP` value may stop the robot from moving as it can't aim the
target and find the direction.
● When the visual line following function is enabled, the video screen will automatically become
binarized results, making the visual analysis clearer.
● `Hard Ware` window displays CPU temperature, CPU occupancy rate, and memory usage of the
Raspberry Pi.
●`Actions`window control unique functions of the robot:
(Google Chrome was
(here Google Chrome), type in the IP
