Convert the picture to black and white, and then binarize (the value of each pixel in the picture is 255
except 0)
'''
img = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
retval, img = cv2.threshold(img, 0, 255, cv2.THRESH_OTSU)
img = cv2.erode(img, None, iterations=6)
colorPos = img[linePos]
try:
lineColorCount_Pos = np.sum(colorPos == lineColorSet)
(line width)
lineIndex_Pos = np.where(colorPos == lineColorSet)
point of the line in the linePos line
'''
Use the endpoint position and line width to calculate the position of the center point of the line
'''
left_Pos = lineIndex_Pos[0][lineColorCount_Pos-1]
right_Pos = lineIndex_Pos[0][0]
center_Pos = int((left_Pos+right_Pos)/2)
print('The position of the center point of the line is：%d'%center_Pos)
except:
'''
If no line is detected, the line width above 0 will cause an error, so that you know that no line has
been detected
'''
center_Pos = 0
print('No line detected')
'''
Draw a horizontal reference line
'''
cv2.line(img,(0,linePos),(640,linePos),(255,255,64),1)
if center_Pos:
'''
If a line is detected, draw the center point of the line
'''
cv2.line(img,(center_Pos,linePos+300),(center_Pos,linePos-300),(255,255,64),1)
# encode as a jpeg image and return it
yield cv2.imencode('.jpg', img)[1].tobytes()
#Use Corrosion Denoising
#Get an array of pixel values for linePos
#Get the number of pixels of line color
#Get the horizontal position of the end
