1. Specifications

1-1. Specifications
Fluid
Proof pressure
Max. operating pressure
Min. operating pressure
Ambient and fluid
temperature
Lubrication
Stroke length tolerance
Cushion
Piston speed
Action
※Depending on the system configuration selected, the specified speed may not be satisfied.
*1 Max. operating pressure and piston speed are different from those of the existing model
(MB series).
Use the actuator with allowable kinetic energy or less.
｛Refer to 2-6. Allowable kinetic energy (Page 9)｝
Warning
！
Confirm the specifications.

These product are designed only for use in compressed air systems (including vacuum).
Do not operate at pressures or temperatures, etc., beyond the range of specifications, as this
can cause damage or malfunction. (Refer to the specifications.)
We do not guarantee against any damage if the product is used outside of the specification
range.
Confirm the applicable specification range.

These product specification apply to standard strokes, including intermediate strokes.

2. Installation and Handling

2-1. Air supply

The compressed air supplied to the cylinder should be filtered by SMC AF series air filter and
regulated to the specified set pressure by SMC AR series regulator.
Warning
！
Type of fluids

Use compressed air.
When there is a large amount of drainage.

Compressed air containing a large amount of drainage can cause malfunction of pneumatic
equipment. An air dryer or water separator should be installed upstream from filters.
Drain flushing

If condensation in the drain bowl is not emptied on a regular basis, the bowl will overflow and
allow the condensation to enter the compressed air lines. It causes malfunction of pneumatic
equipment.
If the drain bowl is difficult to check and remove, installation of a drain
bowl with an auto drain option is recommended.
Use clean air.

Do not use compressed air that contains chemicals, synthetic oils including organic solvents,
salt or corrosive gases, etc,as it can cause damage or malfunction.
Caution
！
When low dew point air is used as the fluid, degradation of the lubrication properties inside

the equipment may occur, resulting in reduced reliability (or reduced service life) of the
equipment.
Consider using low dew point products such as 25A-series.
Air
1.0MPa
0.7MPa *1
0.05MPa
5 to 60°C
Not required (non-lube)
+2.0
0
Non-adjustable air cushion + rubber bumper
50 to 500 mm/s*1
Double acting, Single rod
