SMC Networks MQQT Series Manual

Low Friction Cylinders
NEW NEW NEW
ø30, ø40
newly added
Standard type
Lateral load
resisting type
(Built-in ball bushing)
Standard type
MQML
High speed/frequency
Series
MQP
CAT.ES20-156
Metal Seal Type
Low Friction Cylinder
Series
Bore size Operating pressure range
Series
(mm)
10
MQQT
0.005 to 0.5
16
20
MQQL
25
0.005 to 0.7
30
40
Lateral Load Resisting
Low Friction Cylinder
Series
Bore size Operating pressure range
Series
(mm)
6
(Standard only)
ø6: 0.02 to 0.7
MQML
10
ø10 to ø25: 0.005 to 0.7
16
H
20
0.01 to 0.7
25
Low Friction Cylinder
(Single Acting)
Series
Bore size Operating pressure range
(mm) (MPa)
ø4
ø6
0.001 to 0.7
ø10
(Except for
ø16
moving parts weight)
ø20
C
Compact
MQQ
Actuation speed
(MPa) (mm/s)
0.3 to 300
0.5 to 500
MQM
Actuation speed
(MPa) (mm/s)
0.5 to 1000
5 to 3000
MQP
Thrust control standard
(N)
0.01 to 8
0.03 to 19
0.08 to 50
0.20 to 140
0.30 to 200
