Contents 1. Safety Instructions-------------------------------------------- P. 2-6 2. Specifications ------------------------------------------------- P. 7 3. Construction --------------------------------------------------- P. 7 4. How to Order -------------------------------------------------- P. 8 5. Dimensions ---------------------------------------------------- P. 8...
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 4
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
Page 5
(6) Play in the axial direction JT series has play in the axial direction. (Default: 0.15 mm or less) When positioning the driven object, avoid the influence of play using a knock pin or external stopper.
Page 6
Mounting Warning ! (1) Maintenance space Allow sufficient space for maintenance and inspection. (2) Operate the socket by hand before mounting to ensure it moves smoothly. The dust cover may stick to the socket. Move the dust cover at the base of the socket with fingers, or twist the socket right and left gently to free it before mounting.
Page 7
(1) Use the product so that the kinetic energy does not exceed the allowable value of the cylinder. The JC*M series cylinder is recommended to be used with the JT series. When operating the equipment, adjust the stroke end velocity according to the load so that the kinetic energy is no more than that of the allowable value of the cylinder.
- Spare parts Part name Part No. Applicable model P215420-07 For JT20 Dust cover P215432-07 For JT32 P215440-07 For JT40 4. How to Order Applicable cylinder Symbol Nominal screw size For φ20 M8×1.25 For φ25 M10×1.25 For φ32 M10×1.25 For φ40 M14×1.5 5.
