SMC Networks JAS-S Series Operation Manual

Speed controller with indicator compact type
Hide thumbs Also See for JAS-S Series:

Advertisement

Quick Links

Doc.no.DOC1019547
PRODUCT NAME
Speed controller with indicator Compact Type
MODEL/ Series/ Product Number
JAS-S*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JAS-S Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks JAS-S Series

  • Page 1 Doc.no.DOC1019547 PRODUCT NAME Speed controller with indicator Compact Type MODEL/ Series/ Product Number JAS-S*...
  • Page 2 Doc.no.DOC1019547 Contents 1.Saftey Instructions 3~4 2.Specific Product Precautions 5~10 3.Applications 4.Specifications 5.Malfunctions and Countermeasures 6.Construction 12~13 - 2 -...
  • Page 3: Safety Instructions

    Doc.no.DOC1019547 Speed controller with indicator Compact Type JAS-S* Series Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
  • Page 4: Limited Warranty And Disclaimer/Compliance Requirements

    Doc.no.DOC1019547 Speed controller with indicator Compact Type JAS-S* Series Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
  • Page 5: Design/ Selection

    Doc.no.DOC1019547 2.Specific Product Precautions Design/ Selection Parts and Names of Products Caution (1) The flow rate characteristics for each product are representative values. Knob The flow-rate characteristics are those of each individual product. Actual values may differ depending on the piping, circuitry, pressure Body A conditions, etc.
  • Page 6 Doc.no.DOC1019547 Mounting Mounting Warning Caution (5) Do not apply excessive force or shock to the (1) Keep the instruction manual and check its body or fittings with an impact tool. contents. It can cause damage or air leakage. Install the products and operate it only after reading the operation Manual carefully and (6) For handling One-touch fittings, refer to the understanding its contents.
  • Page 7 Doc.no.DOC1019547 Mounting Mounting Caution Caution (5)-1 For M3,M5,10-32UNF (5)-2 For R, NPT, G thread ①Tightening method ②Chamfered area of female thread First, tighten it by hand, then give it an additional By chamfering as shown in the table below, 1/6 turn to 1/4 turn with a hexagon wrench. Refer machining of threads is easier and effective for to Table below for reference.
  • Page 8 Doc.no.DOC1019547 Piping Threads with Sealant Precautions for One-Touch Tube Fittings Caution Mounting/Piping (1) If the fitting is tightened with excessive Caution torque, a large amount of sealant will seep out. Remove the excess sealant. (1) Connection and disconnection of tube from one-touch fitting (2) Insufficient tightening may loosen the ①...
  • Page 9 Doc.no.DOC1019547 Precautions for One-Touch Tube Recommended Piping Conditions Fittings (1) When connecting piping to the One-touch fitting, use a pipe length with sufficient Mounting/Piping margin, in accordance with the piping conditions shown in Figure 1. Caution Also, when using a tying band, etc., to bind the piping together, make sure that external (2) Connection of the metal rod accessories force does not come to bear on the fitting.
  • Page 10: Air Supply

    Doc.no.DOC1019547 Air Supply Maintenance Warning Warnnig (4) Use clean air (1) Do not disassemble the product or make any Do not use compressed air that contains modifications. chemicals, synthetic oils that include organic Do not disassemble the product or make any solvents, salt, corrosive gases, etc., as it can modifications,including additional machining.
  • Page 11: Specifications

    Doc.no.DOC1019547 3.Application This product is designed to control the speed of a pneumatic actuator. 4.Specifications Model JAS-S Fluid Proof pressure 1.05MPa 0.7MPa Maximum operating pressure 0.05MPa Minimum operating pressure -5~60℃(No freezing) Ambient and fluid temperature Applicable tube materials (note 1) Nylon, soft nylon, polyurethane ,FEP,PFA Note1: Pay attention to the maximum operating pressure for soft nylon and polyurethane.
  • Page 12 Doc.no.DOC1019547 6.Construction Seal method/Gasket seal For M3,M5,10-32UNF Meter-out type Meter-in type Component Parts Description Material Note Body A Body B Needle Indicator Stopper Stainless-steel Needle guide Brass Electroless nickel Plated Disk seal HNBR Stud Brass Electroless nickel Plated O-ring O-ring O-ring O-ring Seal...
  • Page 13 Doc.no.DOC1019547 Seal method/Sealant Seal method/Face seal For R,NPT For G Meter-out type Meter-in type Component Parts Description Material Note Body A Body B Needle Indicator Stopper Stainless-steel Needle guide Brass Electroless nickel Plated Disk seal HNBR Stud Brass Electroless nickel Plated O-ring O-ring O-ring...
  • Page 14 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 URL https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2022 SMC Corporation All Rights Reserved...
