PANEL DESCRIPTION

■ Software Keys

Various often-used functions are assigned
to the Software Keys for easy access. The
functions' icons are displayed above the
Software Keys, as shown below.
D Selecting a Software Key
function
P ush [◄] or [►] to slide through the
selectable functions that are assigned to
the Software Keys.
Push the Software Key under the function's
icon to select the function.
NOTE: The displayed icons or their order
may diff er, depending on the transceiver
version or the presetting.
When the MMSI code is not set, the
Software Keys for the DSC function are
not displayed.
5
FELLECS-TECH | inbox@fellecs-tech.com | www.fellecs-tech.com
D Software Key functions
Compose Distress [DTRS]
Push to display the "COMPOSE DISTRESS"
screen to select the nature of distress, then
to make a call.
NEVER MAKE A DISTRESS CALL IF
YOUR VESSEL OR A PERSON IS NOT
IN AN EMERGENCY. A DISTRESS
CALL SHOULD BE MADE ONLY WHEN
IMMEDIATE HELP IS NEEDED.
Compose other DSC [DSC]
Push to compose an Individual call, Group
call, All Ships call or a Test call, and so on.
Task List [TASK]
(For only the USA version)
Push to enter the Task List.
L Displayed only when "Multiple" is selected
in the "Procedure" in the Menu screen.
Unread List [UNREAD]
Push to enter the Unread List.
L Displayed only when "Single" is selected in
the "Procedure" in the Menu screen.
DISPLAY [DISP]
(For only the IC-M510BB)
Push to
switch the main screen between the
INFO, the Plotter, and the MOB screens
Range [RANGE]
(For only the IC-M510BB)
Push to select the plotter display range on
the Plotter screen.
L Displayed only on the plotter screen.
Target Select [SEL ◄]/[SEL ►]
(For only the IC-M510BB)
Push to select an AIS target, or MOB.
L Displayed only on the plotter screen.
Target Details [INFO]
(For only the IC-M510BB)
Push to display the details on the selected
target.
L Displayed only on the plotter screen.
(p. 20)
(p. 23)
(p. 43)
(p. 43)
(p. 3)
(p. 53)
(p. 53)
(p. 57)
