Hardware Installation and Reference Guide
XG-SFP-ILR-
SM1310-I
Table 7-2 Cabling Specifications of SFP Transceivers
Model
GE-SFP-LX20-
SM1550-BIDI
2.5G-SFP-LX03-
SM1550-BIDI
XG-SFP-ILR-
SM1310-I
Caution

For optical transceivers with a cabling distance of over 40 km/24.85 miles (including 40 km), install an
optical attenuator to avoid overload on the optical receiver when using short-distance single-mode fibers
(SMFs).

An optical transceiver is a laser transceiver. Do not look into the laser beam to avoid burning your eyes.

To keep an optical transceiver clean and dust-free, make sure that the unused ports remain capped.
Table 7-3 Pairing of BIDI Optical Transceivers
Rate/Distance
1000 Mbps/10 km
1000 Mbps/3 km
10 Gbps/1 km
Caution
BIDI optical transceivers must be used in pairs. For example, if GE-SFP-LX20-SM1550-BIDI is used at one
end, GE-SFP-LX20-SM1310-BIDI must be used at the other end.
7.3

Recommended Cabling

When the device is installed in a standard 19-inch rack, route the cables through the cable management brackets.
Top cabling or bottom cabling is adopted according to the actual situation in the equipment room. All conversion
1310 SMF
Connector Type Fiber Type
LC SMF
LC SMF
LC SMF
Supported
Core Size (μm)
9/125
9/125
9/125
Pairing Models
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LX20-SM1310-BIDI
2.5G-SFP-LX03-SM1550-BIDI
2.5G-SFP-LX03-SM1310-BIDI
XG-SFP-ILR-SM1310-I
39
–8.2 –12.6
0.5
Max. Cabling Distance
20 km
3 km
1.4 km
Appendix
0.5
