Figure 7-7 Cable Fastening
○
Hard power cords should be fastened in the terminal connection area to prevent stress on terminal
connection and cable.
○
Do not use self-tapping screws to fasten terminals.
○ Power cords of the same type and in the same cabling
bundle. The power cords in the bundle should be clean and
○ Bundle up cables using cable ties.
Table 7-4 Cable Bundling
Cable Bunch Diameter
10 mm (0.39 in.)
10 mm to 30 mm (0.39 in. to 1.18 in.)
30 mm (1.18 in.)
○ No knot is allowed in cabling or bundling.
○
For wiring terminal sockets (such as circuit breakers) with
insulated terminal should not be exposed outside the terminal block during
orientation should be bundled up into one cable
straight.
Distance Between Every Binding Point
80 mm to 150 mm (3.15 in. to 5.91 in.)
150 mm to 200 mm (5.91 in. to 7.87 in.)
200 mm to 300 mm (7.87 in. to 11.81 in.)
insulated terminals, the metal part of the
42
Appendix
assembling.
