QIFD 0010 - QIFD 0080
52401-100, December 2000
The wiring must be in accordance with NFPA 70 National Electrical
Code, state and local codes. Failure to abide by the national, state and
local codes must result in physical harm and/or property damage.
High voltage may cause personal injury or death. Disconnect
and lockout/tagout per O.S.H.A. regulation 1910.147 all electrical
power supplies before opening the electrical enclosure or
servicing.
Never assume a unit is safe to work on just because it is not
operating. It could restart at any time. Follow all safety precau-
tions outlined in SECTION 5, Maintenance.
Electrical enclosures and components must be in compliance
with NEMA environmental ratings for the areas in which they
are being installed.
Refer to the Wiring Diagram Selection Chart to determine the proper
wiring diagram for your model and application.

WIRING DIAGRAM SELECTION CHART

Model Type #
QIFD 433
0010 & &
0015 434
QIFD 435
0025 & &
0055 436
QIFD 437
0050 & &
0065 438
QIFD 439
0080
19
Voltage Version
115/1/60 Automatic
Drain
Sensor
115/1/60 Controlled
Drain
Sensor
115/1/60 Controlled
Drain
Sensor
115/1/60 Controlled
Drain
3501 Wismann Lane, Quincy IL - 62305-3116
Fig.
Page
3-2
pg. 20
3-3
pg. 21
3-4
pg. 22
3-5
pg. 23
Quincy Compressor
