- Page 1 Quincy Refrigerant compressed air dryers QED-300, QED-600, QED-450, QED-250, QED-350, QED-500 Instruction book...
- Page 3 Quincy Refrigerant compressed air dryers QED-300, QED-600, QED-450, QED-250, QED-350, QED-500 From following serial No. onwards: CAQ 500 389 Instruction book Original instructions Copyright notice Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings.
-
Page 4: Table Of Contents
Instruction book Table of contents Safety precautions......................5 ...........................5 AFETY ICONS ......................5 AFETY PRECAUTIONS GENERAL ...................6 AFETY PRECAUTIONS DURING INSTALLATION ....................7 AFETY PRECAUTIONS DURING OPERATION ................8 AFETY PRECAUTIONS DURING MAINTENANCE OR REPAIR General description......................10 ..........................10 NTRODUCTION ............................13 IR SYSTEM .........................14 EFRIGERANT FLOW ......................15 ONDENSATE DRAIN SYSTEM Controller........................17... - Page 5 Instruction book 3.15 ..................28 ALLING UP MODIFYING ADDRESS CONTROL 3.16 IP, G ................30 ALLING UP MODIFYING ATEWAY AND UBNETMASK 3.17 ...................31 ALLING UP MODIFYING SERVICE TIMER SETTINGS 3.18 ................31 ALLING UP MODIFYING THE UNIT OF TEMPERATURE 3.19 ...................32 ALLING UP MODIFYING UNIT OF PRESSURE 3.20 .................32...
- Page 6 Instruction book Problem solving......................53 Technical data.......................57 .........................57 ETTINGS OF FUSES ....................57 EFERENCE CONDITIONS AND LIMITATIONS ..........................58 IR DRYER DATA Pressure equipment directives...................60 Declaration of conformity....................61 2920 7103 90...
-
Page 7: Safety Precautions
Instruction book Safety precautions Safety icons Explanation Danger for life Warning Important note Safety precautions, general General precautions All responsibility for any damage or injury resulting from neglecting these precautions, or non-observance of the normal caution and care required for installation, operation, maintenance and repair, even if not expressly stated, will be disclaimed by the manufacturer. -
Page 8: Safety Precautions During Installation
Instruction book Safety precautions during installation Precautions during installation 1. The dryer must only be lifted using suitable equipment and in accordance with the applicable safety regulations. Loose or pivoting parts must be securely fastened before lifting. It is strictly forbidden to dwell or stay in the risk zone under a lifted load. -
Page 9: Safety Precautions During Operation
Instruction book Also consult following safety precautions: Safety precautions during operation Safety precautions during maintenance or repair. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. -
Page 10: Safety Precautions During Maintenance Or Repair
Instruction book Safety precautions during maintenance or repair Precautions during maintenance or repair 1. Always use the correct safety equipment (such as safety glasses, gloves, safety shoes, etc.). 2. Use only the correct tools for maintenance and repair work. 3. Use only genuine spare parts. 4. - Page 11 Instruction book Also consult following safety precautions: Safety precautions during installation Safety precautions during operation. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein.
-
Page 12: General Description
Instruction book General description Introduction General QED air dryers remove moisture from the compressed air by cooling the air to near freezing point. This causes the water to condense. The condensate is automatically drained. The dried air is warmed up before leaving the dryer. - Page 13 Instruction book QED-250 up to QED-600 - side view The front panel and the side panel can be removed for service operations. Reference Designation Supply cable passage Manual drain valve Automatic drain connection 2920 7103 90...
- Page 14 Instruction book QED-250 up to QED-600 - internal view Reference Name Compressor Condenser Heat exchanger Condenser fan Hot gas bypass valve Capillary tube Refrigerant dryer/filter 2920 7103 90...
-
Page 15: Air System
Instruction book Air system Air flow diagram Air flow diagram Name Reference Heat exchanger Evaporator Water separator Refrigerant compressor Hot gas bypass valve Condenser Refrigerant dryer/filter Capillary Electronic condensate drain Liquid separator Cooling fan Manual drain valve Description Compressed air enters heat exchanger (1) and is cooled by the outgoing cold, dried air. Water in the incoming air starts to condense. -
Page 16: Refrigerant Flow
Instruction book Condensation in the air net cannot occur unless the air is cooled to below the dew point indicated on the control panel. Refrigerant flow Flow diagram Flow diagram Name Reference Heat exchanger Evaporator Water separator Refrigerant compressor Hot gas bypass valve Condenser Refrigerant dryer/filter Capillary... -
Page 17: Condensate Drain System
Instruction book The refrigerant enters evaporator (2), where it withdraws heat from the compressed air by further evaporation at constant pressure. The refrigerant leaves the evaporator and is sucked in again by the compressor. Automatic regulation The condenser pressure must be kept as constant as possible to obtain stable operation. The fan control switch therefore stops and starts the condenser cooling fan (11). - Page 18 Instruction book Control panel Control panel Text on control panel Reference Description Power Alarm Test Table with references Name Description LED "drain voltage on" LED alarm Funtions button The control panel on top of the drain includes a multifunction button and two state display LED's. When LED L1 is continuously on, this indicates that the solenoid valve is energized;...
-
Page 19: Controller
Instruction book Controller Infologic² controller Control panel Control panel General description The Infologic² controller automatically controls the dryer, i.e.: • Monitors the pressure dew point and the digital switches to ensure safe operation. • Stops the dryer whenever necessary. • Restarts the dryer when required. •... -
Page 20: Control Panel
Instruction book Control panel Detailed description Control panel Reference Designation Function Display Shows icons and operating conditions. Automatic operation symbol LED, Automatic operation Indicates that the regulator is automatically controlling the dryer. The dryer is stopped and restarted depending on the air consumption and the data programmed in the regulator. - Page 21 Instruction book Function Icon Description Machine control mode Remote start / stop LAN control Automatic restart Automatic restart after voltage failure is active Timer Indicates a timer is active Service Service required Units Temperature unit Temperature unit Hours The value shown must be multiplied by 1000 to get the actual value Other icons Motor...
-
Page 22: Main Screen
Instruction book Main screen Main screen When the voltage is switched on, the first screen is a test screen. The next screen is the main screen, shown automatically: Main screen, basic indications In above image, the screen shows: • The dryer status (the icon is rotating when the dryer compressor is running, standing still when stopped). •... - Page 23 Instruction book Overview of the screens Digital input Designation Related topic screens <d. in> Status of the digital inputs See section Digital inputs <d. 1> Running hours See section Calling up running hours <d. 2> Motor starts See section Calling up motor starts <d.
- Page 24 Instruction book Test screens Designation Related topic <t. 1> Display test See section Test screens Menu flow Simplified menu flow Ref. Description Ref. Description Dew point (main screen) (13) Temperature unit Ambient temperature (14) Pressure unit Digital input status (15) Auto restart function Running hours (16)
-
Page 25: Calling Up Ambient Temperature
Instruction book Ref. Description Ref. Description Actual program version (20) Fixed alarm setting LAN selection (21) Flexible alarm setting (10) Settings node ID (22) Low dew point alarm and shutdown setting (11) IP settings (23) High ambient alarm and shutdown setting (12) Service timer setting (24) -
Page 26: Calling Up Running Hours
Instruction book Contact Description Value Status No problem Flow switch No flow Air flow Calling up running hours Calling up running hours Starting from the Main screen, press Scroll button (12) until <d. 1> is shown and then press Enter button (13). A screen similar to the following appears: The number of hours is shown in <hrs>... -
Page 27: Calling Up/Resetting The Service Timer
Instruction book In the example shown, the screen shows the unit used (hrs) and the value (5000): the regulator module has been in service during 5000 hours. 3.11 Calling up/resetting the service timer Calling up the service timer The controller has a built-in timer to give a warning when certain maintenance activities are to be carried out. Starting from the Main screen, press Scroll button (12) until <d. -
Page 28: Shut-Down Warning
Instruction book 3.12 Shut-down warning Description A shutdown warning will appear in the event of: • A too low or too high dew point temperature • A too high ambient temperature • A drain fault The dryer remains running. Alarm LED (5) is lit. The alarm disappears automatically when the abnormal condition ends. -
Page 29: Shut-Down
Instruction book Drain alarm The drain alarm appears when: • The drain is not able to drain all the condensate. • The compressed air pressure is too low. • During initial start-up it may indicate that the automatic drain is connected wrongly. See section Problem solving. -
Page 30: Selection Between Local, Remote Or Lan Control
Instruction book Main screen with ambient temperature alarm The display still shows the dew point (30 °C - 86 °F), but the ambient icon is flashing. Main screen with dew point sensor alarm The display shows <Err> and the dew point icon is flashing. Press the Escape button (14) to reset and restart the dryer manually. - Page 31 Instruction book If desired the user can change this ID. Press the Enter button (13): the node ID value starts blinking. Use the Scroll buttons (12) to change the node ID. Press the Enter button (13) to program the new node ID or press the Escape button (14) to leave this screen or to cancel this operation.
-
Page 32: Calling Up/Modifying Ip, Gateway And Subnetmask
Instruction book After modifying the settings, the screen may look as follows: 3.16 Calling up/modifying IP, Gateway and Subnetmask Calling up Starting from the Main screen, press the Scroll button (12) until <P. 3> is shown and then press Enter button (13). -
Page 33: Calling Up/Modifying Service Timer Settings
Instruction book 3.17 Calling up/modifying service timer settings Calling up/modifying service timer settings Starting from the Main screen: • Press Scroll button (12) until <P. 4> is shown and then press Enter button (13): the setting of the service timer is shown in <hrs> (hours) or <x1000 hrs> (hours x 1000). Example: <4000 hrs> means the timer is set at 4000 running hours. -
Page 34: Calling Up/Modifying Unit Of Pressure
Instruction book Press Enter button (13) (unit starts blinking) and use the Scroll buttons (12) to select another unit of temperature. Press Enter button (13) to program the new unit. Press Escape button (14) to return to the parameter screen. 3.19 Calling up/modifying unit of pressure Calling up/modifying unit of pressure In a similar way as explained in section... -
Page 35: Calling Up/Modifying Flow Switch Function
Instruction book 3.21 Calling up/modifying flow switch function Description The flow switch monitors the compressed air flow through the dryer. If the function is active and when no flow is detected, the controller stops the dryer. The controller will restart the dryer when air flows through the dryer. -
Page 36: Activating Automatic Restart After Voltage Failure
Instruction book The display now shows all icons that can be displayed: 3.23 Activating automatic restart after voltage failure Description This function allows the compressor to restart automatically after a power failure. This parameter, accessible in screen <P. 7>, can only be modified after entering a code. Consult Quincy if this function is to be activated. -
Page 37: Selection Between Flexible Alarm And Fixed Alarm
Instruction book Lost passwords can not be recovered. Save the password carefully. 3.25 Selection between flexible alarm and fixed alarm Selecting between flexible alarm and fixed alarm The dew point alarm can be set in fixed or flexible mode. If set to fixed mode, an alarm will be triggered when the dew point exceeds the alarm setting (e.g. -
Page 38: Calling Up/Modifying The Low Dew Point Setting
Instruction book <SEt> is the offset value that will trigger the alarm. Press Enter button (13): the programmed value starts blinking. To change, use the Scroll buttons (12). Press Enter button (13) to modify and Escape button (14) to return to the previous screen. It is also possible to adjust the value when the alarm must disappear again. -
Page 39: Calling Up/Modifying High Ambient Temperature Setting
Instruction book 3.29 Calling up/modifying high ambient temperature setting Calling up/modifying high ambient temperature setting In protection parameter set Pr. 3, the High ambient temperature alarm level (<AL-H>) and the High ambient temperature shutdown level (<Sd-H>) can be set. Both values are adjustable between 35 °C (95 °F) and 60 °C (140 °F). -
Page 40: Installation
Instruction book Installation Dimension drawings QED-250 and QED-300 - dimension drawing 2920 7103 90... - Page 41 Instruction book QED-350 up to QED-600 - dimension drawing Reference Name Main supply electrical cable gland M25 Manual drain Automatic drain Cooling air flow Air inlet Air outlet 2920 7103 90...
-
Page 42: Installation Proposal
Instruction book Installation proposal Installation proposal - QED-250 and QED-300 2920 7103 90... - Page 43 Instruction book Installation proposal - QED-350 up to QED-600 Text on drawings: 2920 7103 90...
- Page 44 Instruction book Reference Description Standard dryer Dryer installation proposal with reference to minimum needed free area Ventilation proposal Service side Top view Service front Air flow inlet Side view Air flow (10) Front (11) Floor Instructions Reference Description The inlet grids and ventilation fan should be installed in such way that any recirculation of the cooling air is avoided.
-
Page 45: Electrical Connections
Instruction book Electrical connections Electrical connections 1. Provide an isolating switch nearby the dryer. 2. Check that the electric cables and wires inside the electric cabinet are clamped tight to their terminals. 3. Check the fuses and the setting of the overload relay. See section Settings of fuses. - Page 46 Instruction book Electrical diagram for three-phase units Typical designations used in the electrical diagrams Reference Designation Customer’s installation Flow switch Alarm EWD Remote start/stop Electronic drain 1X0/6 Terminals F1-6 Fuses 2920 7103 90...
-
Page 47: Pictographs
Instruction book Reference Designation Internal protection Relay ON/OFF compressor and fan Auxiliary relay, general warning Auxiliary relay, general shut-down K05/6 Auxiliary relay, forced drain Contactor compressor Contactor fan motor Phase sequence relay Auxiliary relay (alarm functions) Compressor Fan motor PSHH13 High pressure switch PSR12 Fan switch... - Page 48 Instruction book Reference Description Warning, voltage Information label refrigerant: Contains fluorinated greenhouse gases covered by the Kyoto Protocol. 2920 7103 90...
-
Page 49: Operating Instructions
Instruction book Operating instructions Warnings Safety precautions The operator must apply all relevant safety precautions, including those mentioned in this manual. Altitude operation Consult your supplier if operating above 3000 m (9843 ft). Initial start Procedure Control panel Step Action A few minutes before starting, the main supply to the dryer must be switched on to initialize the Infologic²... -
Page 50: Starting
Instruction book Starting Control panel Control panel Procedure To prevent that wet air gets into the compressed air circuit, it is advised to follow next procedure: Step Action Switch on the main supply to the dryer a few minutes before starting, to allow the Infologic² and the flow switch to initialize. -
Page 51: During Operation
Instruction book During operation Description Control panel Regularly check: • The pressure dew point on the display of the control panel. The pressure dew point will deviate from nominal if the air inlet conditions or volume flow differ from nominal. •... - Page 52 Instruction book Procedure Step Action Close dryer inlet and outlet valves (customer's installation). Press stop button (11). The dryer stops. Voltage on LED (4) remains lit. Leave the voltage on if the dryer has to remain on stand-by. 2920 7103 90...
-
Page 53: Maintenance Instructions
Instruction book Maintenance instructions Attention Cooling dryers of QED type contain refrigerant HFC. Safety precautions When handling refrigerant, all applicable safety precautions must be observed. Please be aware of the following points: • Contact of refrigerant with the skin will cause freezing. Special gloves must be worn. In case of contact with the skin, the skin should be rinsed with water. - Page 54 Instruction book Preventive maintenance schedule Period Operation Daily Check that condensate is discharged during operation Weekly Drain cleaning: open the manual drain valve during a few seconds. Hold a towel against the drain outlet when opening. Monthly Drain inspection: press the test button on top of the electronic water drain (EWD) Condenser cleaning: proceed as follows: •...
-
Page 55: Problem Solving
Instruction book Problem solving Warnings • Before starting any maintenance or repairs, close the air outlet valve and press the test button on top of the electronic water drain to depressurise the air system. • Apply all relevant instructions in section Safety precautions during maintenance or repair. - Page 56 Instruction book Condition Fault Remedy Condensate trap remains Automatic drain system clogged Flush the assembly by opening inoperative the manual drain valve. Have system inspected Clean the inlet filter of the automatic drain Condition Fault Remedy Condensate trap continuously Automatic drain system out of order Have system checked, if discharges air and water necessary replace automatic drain...
- Page 57 Instruction book Dew point alarm visible (red light and blinking dew point icon) Condition Fault Remedy Dryer does not start Circuit has not cooled down Wait 1 minute before restarting the dryer Condition Fault Remedy Too high flow or inlet temperature too Dryer undersized Try running in regular mode high...
- Page 58 Instruction book Condition Fault Remedy LED L2 lights up and no drain alarm Note: In alarm situations, the drain valves make an automatic series of on the display forced openings (2 seconds ON; 2 seconds OFF) Slow draining or no draining The feed line has insufficient slope Lay the feed line with an adequate slope...
-
Page 59: Technical Data
Instruction book Technical data Settings of fuses Overload relay and fuses QED-250 QED-300 QED-350 Frequency (Hz) Voltage (V) Main fuses, supply Main fuses, supply Main fuses, supply line (A) line (A) line (A) QED-450 QED-500 QED-600 Frequency (Hz) Voltage (V) -
Page 60: Air Dryer Data
All data specified below apply under reference conditions, see section Reference conditions and limitations. Specific data Air dryer type Units QED-250 QED-300 QED-350 Volume flow at dryer inlet 60 Hz Volume flow at dryer inlet 60 Hz Pressure drop over dryer without filters, 60 Hz 0.11... - Page 61 Instruction book Air dryer type Units QED-450 QED-500 QED-600 Dryer mass (approx.) Dryer mass (approx.) 2920 7103 90...
-
Page 62: Pressure Equipment Directives
Components subject to 97/23/EC Pressure Equipment Directive greater than or equal to category II Dryer type Part number Description PED Class QED-250 up to QED-600 1089 9139 14 High pressure switch QED-250 and QED-300 1624 2274 00 Heat exchanger QED-350 1624 2275 00 Heat exchanger QED-450 up to QED-600 1624 2276 00... -
Page 63: Declaration Of Conformity
Instruction book Declaration of conformity Typical example of a Declaration of Conformity document (1): Contact address: Quincy Compressor 701 North Dobson Avenue Bay minette, AL 36507 United States 2920 7103 90... - Page 66 Performance You Demand. Reliability You Trust. www.quincycompressor.com...
