Instruction Manual
This manual contains important safety information and should be made available to
all personnel who operate and/or maintain this product. Carefully read this manual
before attempting to operate or perform maintenance on this equipment.
Manual No. 65107-1B
February 2009 Edition
Advertisement
Table of Contents
Related Manuals for Quincy Compressor QHPR Series
Summary of Contents for Quincy Compressor QHPR Series
- Page 1 QHPR Series (5, 10 &15 SCFM Compact /Climate Control Refrigerated Compressed Air Dryers Instruction Manual This manual contains important safety information and should be made available to all personnel who operate and/or maintain this product. Carefully read this manual before attempting to operate or perform maintenance on this equipment.
-
Page 3: Table Of Contents
Receiving, Unpacking and Moving .................. Installation ...........................3 Instrumentation ........................4 Start-up & Operation ......................5 Shutdown ..........................5 Maintenance ........................6 Returns to Manufacturer ...................... Field Service Guide ...................... Troubleshooting ........................ Technical Data ........................10 Electrical Schematic ......................11 Air & Refrigerant Flow Schematic ..................11 Quincy Compressor-QGB ™... -
Page 5: Standard Warranty
Products repaired or replaced under or supplied in connection with the sale of warranty shall be warranted for the manufacturer’s products. unexpired portion of the warranty applying to the original product. Quincy Compressor-QHPR Series Dryers... -
Page 6: Safety Precautions
• Air treated by this equipment may not IMPORTANT: Do not store dryer in be suitable for breathing without further temperatures above 130°F (54.4°C). purification. Refer to applicable standards and specifications for the requirements for breathing quality air. Quincy Compressor-QHPR Series Dryers... - Page 7 See Engineering Data section for access. Install the dryer with the frame dryer inlet and outlet connections. level. Anchor bolts are not required. Quincy Compressor-QHPR Series Dryers...
-
Page 8: Instrumentation
A float operated drain housed in a QHPR dryers are equipped with an ON/ metal bowl will automatically drain the OFF switch on the front panel. A light condensate on all QHPR model dryers. signals when the dryer is on. Quincy Compressor-QHPR Series Dryers... -
Page 9: Start-Up & Operation
. Disconnect the main power supply. compressed air system under pressure If mechanical repairs are to be made or may cause equipment failure and serious service is performed, vent the internal personal injury. pressure of the dryer to atmospheric Quincy Compressor-QHPR Series Dryers... -
Page 10: Maintenance
Inspect the condenser coils. Remove accumulated dust and dirt with a soft 3245021 3245021 wItcH brush or with air from an OSHA approved 3090900 3090900 lOat RaIn compressed air nozzle that limits the discharge pressure to 30 psig. Quincy Compressor-QHPR Series Dryers... -
Page 11: Returns To Manufacturer
Work on the refrigeration and property damage. system must be done only by a competent Before dismantling any part of the dryer or refrigeration mechanic. compressed air system, completely vent the internal pressure to the atmosphere. Quincy Compressor-QHPR Series Dryers... - Page 12 & xcessive airflow heck airflow system capacity educe airflow or resize aNd replace system oNdeNser fouled or leaN coNdeNser clogged igh ambieNt temperature eNtilate area mproper adjustmeNt of oNsult actory xpaNsioN alve Quincy Compressor-QHPR Series Dryers...
- Page 13 Problem: High Pressure Drop Symptoms: Possible causes: Remedy: outlet pressure ryer uNdersized cause heck airflow dryer water dowNstream dryer capacity educe airflow resize replace dryer & locked separator ismaNtle cleaN replace separator ryer freeziNg oNsult local distributor Quincy Compressor-QHPR Series Dryers...
- Page 14 40°f - 122°f 40°f - 122°f Nlet emperature compressed iNlet dryer 40°f - 113°f 40°f - 113°f mbieNt emperature 100°f , 100 , 100% atiNg coNditioNs iNlet temperature psig iNlet pressure iNlet relative , 100°f @ 60h cagi adf-100 humidity ambieNt temperature r efer dryer data plate refrigeraNt charge Quincy Compressor-QHPR Series Dryers...
-
Page 15: Electrical Schematic
WITH RUNNING LAMP COMP. PTC STARTER OVERLOAD PROTECTOR Air & Refrigerant Flow Schematic HEAT EXCHANGER REHEATER EVAPORATOR AIR INLET AIR OUTLET CHILLER AUX. CONDENSER SEPARATOR LIQUID RECEIVER/ DRAIN FILTER DRYER OUTLET CONSTANT PRESSURE EXPANSION VALVE REFRIGERANT COMPRESSOR Quincy Compressor-QHPR Series Dryers... - Page 16 ENVIRONMENTAL AND OSHA REQUIREMENTS: At the time of shipment of the equipment from the factory, Quincy Compressor / Ortman Fluid Power will comply with the various Federal, State and local laws and regulations concerning occupational health and safety and pollution. However, in the installation...
- Page 17 Seller is not responsible for loss or damage in transit after having received “In Good Order” receipt from the carrier. All claims for loss or damage in transit should be made to the carrier. Quincy Compressor-QHPR Series Dryers...
- Page 18 Notes _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________ _ _________________________________________________________________________...
- Page 20 Dryer Department: 724.746.1100 SPXDocument #: 5003991 E-mail: info@quincycompressor.com © 2009 Quincy Compressor Website: quincycompressor.com All Rights Reserved. Litho in U.S.A.
