Hydraulic system

Hydraulic system is mainly composed of hydraulic unit, rubber tube and lifting cylinder.
5
1
2
3
1. Lifting cylinder
4
2. Hydraulic unit
3. Multi-way valve
4. tank
5. Hose connector
63
Figure 2-5 Hydraulic system
