2.3 Display and control

Item
11 Belly switch
12 Forward and backward switch
13 password keyboard
14 Electricity meter
Electricity meter display function
Power display: ten levels display the percentage of remaining power;
Power shortage reminder: flashing reminder when there is 15% remaining power, the frequency is
1 time/second;
State memory: power on after power off, power can be displayed in memory;
Hour meter: digital display of the current accumulated working time of the vehicle, maximum 6
digits display (1 digit after the decimal point); unit: h;
In the CAN version, it can communicate with the electronic control to obtain the power, speed and
fault code; (CAN protocol support required)
11
12
13
Description
17
16
15
14
Item
15 Horn
16 Fork down button
17 Fork lifting button
8
