5.4 Replacing battery

操作步骤：
–Park the vehicle safely as required.
–Remove the fixing bolts and open the hood.
–Unplug the wiring harness from the battery.
–Remove the battery fixing device bolts.
–Take out the fixing plate in the direction shown in the figure.
–Remove the remaining fixing plate to take out the battery
The installation process is opposite to the removal process
WARNING

Battery is very heavy, be careful to avoid damage.

Disposal to the waste battery should accord with local environment regulation.

When replacing the battery, ensure that a battery of the same specification,
dimension and weight is fitted.
