CyberData VoIP Ceiling Speaker Operation Manual page 32

26
Mount the Speaker
CyberData Corporation
Figure A-1. VoIP Speaker Assembly
DRY WALL MOUNTING KIT
PLASTIC RIBBED ANCHOR (3x)
#8 NYLON
THUMBNUT (3X)
#8 FENDER
WASHER (3X)
CEILING
TEMPLATE
VoIP SPEAKER
ASSEMBLY
MOUNTING
SCREW
8-32x1 1/4" (3X)
DRY WALL MOUNTING KIT
#6 SCREW (3x)
2. Plug the Ethernet cable into the Speaker Assembly.
Operational and Linked to the Network"
3. At this point:
• For drop ceiling mounting, position the VoIP SPEAKER ASSEMBLY in the ceiling so that its
screw holes align with those you prepared.
• For drywall mounting, place the three PLASTIC RIBBED ANCHORS in the holes you
prepared, and position the VoIP SPEAKER ASSEMBLY over them, aligning the screw
holes in the assembly with the anchors.
VoIP SPEAKER ASSEMBLY
120°
120°
Section 2.2.2, "Confirm that the Speaker is
explains how the Link and Status LEDs work.
930095H
3
" HOLE (3x)
16
3
"
8
7 1 4 " HOLE
080169B.dwg
Operations Guide
