CyberData VoIP Ceiling Speaker Operation Manual page 25

2. On the MGROUPS Setup page, enter values for the parameters indicated in
Web Page Item
Device Name
MG-Emergency
MG-(1-8)
MG-Background
Multicast IP Address
Port 2000-65535
Priority
MGROUP Name
Beep
3. After changing the parameters, click Save Settings.
Note
Operations Guide
Table 2-8. MGROUPS Setup Parameters
For information on how to set up MGROUPS in Cisco Call Manager Express,
see Appendix D, "Setting Up MGROUPS in Cisco Call Manager
930095H
Description
Displays the device name.
Use MG-Emergency for the MGROUP with the highest
priority.
Use MG-(1-8) to assign MGROUPS 1 through 8.
Use MG-Background for the MGROUP with the lowest
priority (background audio for example).
Enter the multicast IP Address for this MGROUP.
Enter the port number for this MGROUP.
Assign the priority for this MGROUP (the higher the number,
the higher the priority).
Assign a descriptive name for this MGROUP.
Check this box if you want a beep to precede a page.
Click this button to save your configuration settings.
Click this button to reboot the system.
Link to the Network Setup page.
Link to the Speaker Setup page.
Link to the SIP Setup page.
Link to the Upgrade Firmware page.
Link to the Home page.
Installing the VoIP Ceiling Speaker
Set up the MGROUPS
Table 2-8.
Express".
CyberData Corporation
19
