Sheet - Omron CX-DESIGNER - INTRODUCTION GUIDE Introduction Manual

Start up Creating a
CX-D new project

20. Sheet

20. Sheet
Select the Sheet icon.
Enter "Sheet 1" in Title.
Click
Project
property
Sheet is a screen that is able to be overlapped on a normal screen and displayed.
If you create functional objects on a sheet that you want to use for more than one
screen, those objects can be used on all screens applied to the sheet just by setting at
[apply sheet].
In this manual, you will create a Switch Label button, a Pop-up Display button, and a
Switch Screen button in the sheet, that are commonly used on screens 1 to 3.
System Creating
setting a screen
A new sheet is created.
Transferring
Validation
a project
