Pop-up Screen

Pop-up Screen
A pop-up screen is a small screen that can be displayed as needed on top of
another screen.
You will create a pop-up screen that turns ON/OFF the PLC allocation
addresses 00001.00 to 0001.05, and 00002.00 to 0002.05 and generate/cancel
virtual alarms.
1. Low Alarm button
Press this button to switch ON/OFF (Occurrence/Recovery).

2. High Alarm button

Press this button to switch ON/OFF (Occurrence/Recovery).
3. Close button
Closes the pop-up screen.
Project System
property setting

Low Alarm buttons

Creating
Validation
a screen
Close button High Alarm button
Transferring
a project
