Start up Creating a
CX-D new project
Sheet 1
Sheet 1
A sheet is a screen that contains objects commonly used on several screens.
In this manual, you will create a sheet with a "Switch Label" function to switch
labels between English and Dutch, a function to display a screen (to be
described later) for generating a virtual alarm, and a function to switch screens.

1. Switch Label Button

Press this button to show a pop-up menu from which you can switch a label in
English and Dutch.

2. Virtual Alarm Display Button

Press this button to display the pop-up screen (to be described later) with a
Virtual Alarm Display button.

3. Screen Switch Button

Press a button to display the screen number (1 to 3) shown on the button .
Project
property
Switch Label Button
System Creating
setting a screen
Virtual Alarm
Display Button
Validation
Screen Switch Buttons
Transferring
a project
