Assembly before installation

The stove leg and the warming oven top might not be assembled
in the factory, in order to save space for transportation and
storage. You must therefore assemble these parts before
installing the cook stove.

Installing legs

1) Take out legs and bricks from combustion chamber.
2) Unscrew the stove from the skids.
3) Lay the stove on its back carefully not to damage the
paint.
4) Loosen the nut (#2) without removing it completely.
5) Install the legs (#1) as illustrated below.
Attention: Make sure the legs are in place, correctly
positioned and in contact with the bottom of the
stove.
PR_I028/2023-08-08-EN

Warmer stove Assembly (Optional)

1- Place the backside on the product package to protect
the painted part.
2- Fix the left side
3- Fix the right side.
4- Attach the front part (with the door) to the two sides
and the back. Leave the horizontal holes empty for
the chrome decoration.
