PLEASE READ CAREFULLY AND KEEP
THIS MANUAL FOR FUTURE REFERENCE
Instruction Manual
STRATO
CUISINIÈRE 3.0
EXO
NEWTON
CUISINIÈRE SE 3.0
MICHIGAN
Tested and listed to
UL 1482
490, rue de l'Argon, Quebec (Quebec) Canada G2N 2C9
Phone.: 418-849-8095
Fax: 418-849-0077
www.jaroby.com
PR_I029/2023-09-05-EN-US
Revision: 8
Printed in Canada
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for J. A. Roby STRATO
Summary of Contents for J. A. Roby STRATO
- Page 1 PLEASE READ CAREFULLY AND KEEP THIS MANUAL FOR FUTURE REFERENCE Instruction Manual STRATO CUISINIÈRE 3.0 NEWTON CUISINIÈRE SE 3.0 MICHIGAN Tested and listed to UL 1482 490, rue de l'Argon, Quebec (Quebec) Canada G2N 2C9 Phone.: 418-849-8095 Fax: 418-849-0077 www.jaroby.com...
-
Page 2: Table Of Contents
Oven Door ................32 Offset Vertical Installation ............21 Annex 2 .................. 33 Vertical Installation ..............22 Replacement parts ............... 33 Combustion air intake ............. 23 J. A. Roby Limited Lifetime warranty ........34 Exterior Air Intake pipe ..............23 PR_I029/2023-09-05-EN-US Revision: 8... -
Page 3: Introduction
appliance would be in the main living area. The draft will be Introduction better because we have more length of chimney. Read all instructions carefully before installing your new J. A. ROBY woodcook stove. A proper installation is very important Warning for a safe and effective use of your stove. -
Page 4: Rating Plate
Rating plate PR_I029/2023-09-05-EN-US Revision: 8... -
Page 5: Appliance Dimensions
ppliance dimensions PR_I029/2023-09-05-EN-US Revision: 8... - Page 6 PR_I029/2023-09-05-EN-US Revision: 8...
-
Page 7: Specifications
Specifications Option STRATO CUISINIERE 3.0 Wood Wood Wood Combustible 1000 – 2 500 ft² 1000 – 2 500 ft² 1000 – 2 500 ft² Recommended surface area 95 000 BTU 95 000 BTU 95 000 BTU Capacity Flue pipe 6 in... -
Page 8: Clearances To Combustibles Materials
Option NEWTON CUISINIERE SE 3.0 MICHIGAN Wood Wood Wood Combustible 1000 – 2 500 ft² 1000 – 2 500 ft² 1000 – 2 500 ft² Recommende d surface area 95 000 BTU 95 000 BTU 95 000 BTU Capacity Flue pipe 6 in 6 in 6 in... -
Page 9: Installation
Installation Dimension of floor protection plate WARNING ALWAYS USE J.A. ROBY PARTS on your The following dimensions are the minimum values according to appliance. Using other differences parts can damage the the desired configuration. appliance and cause injury. No wall around the cookstove Fire Prevention Without water tank Smoke and carbon monoxide emissions... - Page 10 Cookstove is located near of right and back wall Without water tank UNITED STATE ONLY: It’s necessary to protect the floor beneath the horizontal part of chimney connector extending 2 inches (5cm) beyond each side of the pipe. You can extend the floor protection panel while respecting the clearances of each side of stove.
-
Page 11: Minimum Clearances To Combustible Material
Minimum clearances to combustible material This appliance needs a minimum space because of these reduced clearances. Whether in the living room or the dining room, the cookstove will match perfectly by its originality. It requires a MINIMUM clearance of 6 3/8 inches at the back (from the top of cookstove) and 12 inches MINIMUM clearance on the left side (from the top of cookstove) and 4 inches MINIMUM clearance on the right side (from the top of... -
Page 12: Assembly Before Installation
Assembly before installation Attach the front part (with the door) to the two sides The stove leg and the warming oven top might not be assembled and the back. Keep the horizontal holes for the in the factory, in order to save space for transportation and chrome decoration. - Page 13 Fix the right decorative panel and attach it to the right chrome decoration. Remove the side panels of the cook stove. 10) Put and fix the warmer with the 4 bolts of each side to the cook stove. 4 bolt extend out from the surface. 11) Fix the 2 carriage bolts at the front through the chimney hole or the round cook opening.
-
Page 14: Firebricks Installation
Firebricks installation Back firebricks installation Floor firebricks installation Place 4 bricks «A» at the bottom. Put the 3 brick screws in the hole and for this purpose Put 7 bricks «A» and 1 brick« G » in the bottom as shown Do not tighten up these screws too much, so that in the picture. -
Page 15: Firebricks Installation On The Pipes
Firebricks installation on the pipes Make sure that the rockwool over the bricks does not The firebricks must be placed on the 4 pipes from the back of obstruct the passage of smoke. combustion chamber. Bricks keep a maximum heat inside the Put two half metal discs over the rockwool near the rear combustion chamber so that the air coming from the pipes could deflector already in place. -
Page 16: Firebox Configuration & Part List
Firebox configuration & part list List of components: 1) 2 x steel half round discs 2) 1 x ceramic wool 3) 3 screws and brick supports 4) 3 x Ø 3⁄4 ’’ x 19 ’’ simple pipe 5) 2 x Ø 3⁄4 ’’ x 19 ’’ double pipe 6) 1 ash dump plug PR_I029/2023-09-05-EN-US Revision: 8... -
Page 17: General Steps Of Stove Installation
General steps of stove installation Mark the dimensions of protection panel on the floor. Read the entire installation manual before installing The edge clearance of the sides and the back is and using your stove. 8 inches (20.3 cm). At the front, it must be 16 inches(40.6cm) in USA, measured from the front door. -
Page 18: Chimney Connector Installation
Insert entirely the roll formed end into the stove collar and Chimney connector installation screwing it with a minimum of 3 screws. The chimney connector is a set of single wall flue pipes and elbow installed between the stove collar and the chimney collar. Components of single wall chimney connector are available at any hardware store and there is no precise standard or regulation. -
Page 19: General Steps Of Chimney Installation
General steps of chimney installation Use only approved chimneys of the same size as the output of Frame the hole into the roof. the appliance, which means 6 inches in the case of Cookstove. Install a chimney support and a fireguard in the ceiling The chimneys used must be tested according to UL 103 (type where cook stove is installed. -
Page 20: Vertical Installation Inside Masonry Chimney
Vertical Installation Inside Masonry Outside Vertical Installation Chimney The wood cookstove must be installed in accordance with the applicable local laws or the NFPA211 (USA) norms. Follow the The cookstove must be installed in accordance with the chimney manufacturer’s instructions to install the chimney. applicable local laws or the NFPA211 (USA) norms. -
Page 21: Vertical Installation On Cathedral Roof
Vertical Installation on Cathedral Roof Offset Vertical Installation The wood cookstove must be installed in accordance with the The wood appliance must be installed in accordance with the applicable local laws or the NFPA211 (USA) norms. Follow the applicable local laws or the NFPA211 (USA) norms. Follow the chimney manufacturer’s instructions to install the chimney. -
Page 22: Vertical Installation
Vertical Installation The wood appliance must be installed in accordance with the applicable local laws or the NFPA211 (USA) norms. Follow the chimney manufacturer’s instructions to install the chimney. Always pass chimney between joists. If a joist need to be cut, referring to the National Building code to know how to do it safely to avoid structural integrity fail. -
Page 23: Combustion Air Intake
Combustion air intake Installation of Air Intake Pipe To install the exterior air intake pipe, fold the 3 legs of air inlet In conventional designed homes, natural ventilation is enough at the back of the stove. On the other side of the heat shield to operate the wood stove efficiently. -
Page 24: Replacement Stainless Steel Tubes
How to install a tube: Replacement stainless steel tubes Insert the tube into the round hole on the air intake Although the tubes are made of stainless steel, with extreme passage. temperature and conditions the tubes are eventually corroded insert the tube into the hole on the other side. and perforated as normal deterioration. -
Page 25: Operating Instructions
You can control the combustion by turning up or down the Operating Instructions handle. The wood will burn more rapidly when more primary air is set. Otherwise the wood burn more slowly and more efficiently with the handle set to secondary air. You can Control of primary and secondary air balance the primary and secondary air to have more heat for admission... -
Page 26: Operation Of Cooking Holes
FIRE IN THIS HEATER. KEEP ALL SUCH LIQUIDS AWAY Storage of the cooking hole handle FROM THE HEATER WHILE IT IS IN USE. Cooking holes handle is set into the storage hole at the right part of the stove to keep it relatively cold. Operation of cooking holes Cooking holes have removable covers so that you can take them off and put skillets directly over the heat from the smoke. -
Page 27: Opening And Closing Of Warming Oven
Opening and closing of warming oven The spring handles of warming oven are decorative purpose only. When the cook stove is hot, it is strongly recommended to use the cooking cover handle. There is an opening made for this purpose at the top of the warming oven door. To operate the spring handle of warming oven, use isolated mitts. -
Page 28: Maintenance
Maintenance Ash Disposal Ash Removal Some embers are mixed with ash and can remain lit. If embers The wood burning make some residual called ash and it must have enough oxygen, it can stay lit some hours and even some be removed from the combustion chamber to help oxygen few days. -
Page 29: Door Maintenance
Door maintenance Disassembly and reassembly of door Do not unscrew the lower hinge when disassemble the door. The door is the mobile element that need a special attention. Its tightness is primordial. If you see the white soot sticking on Keep the door locked. -
Page 30: Replacing Glass Fiber Rope
Replacing glass fiber rope What to do in case of Chimney Fire When the braided glass fibre rope is all flattened out, it becomes impossible to close the door hermetically. This Contact your local authority to know what to do in case of means that the glass fibre rope is no longer usable or that the Chimney fire. -
Page 31: Annex 1
Annex 1 Door assembly Wood Stove Door *The same assembly for an arc wood stove PR_I029/2023-09-05-EN-US Revision: 8... -
Page 32: Oven Door
Oven Door PR_I029/2023-09-05-EN-US Revision: 8... -
Page 33: Annex 2
Annex 2 Replacement parts • Bricks • Stove ceramic glass • Tempered glass oven door • Spring Handle • Stove door • Oven door • Fans • Flat glass fiber rope (around glass) • Round glass fiber rope • Ash plug •... -
Page 34: J. A. Roby Limited Lifetime Warranty
WOOD BURNING STOVES & FIREPLACES J. A. ROBY’s warranty only applies to original buyer and is non-transferable. This warranty covers brand new products only, which have not been altered, modified or repaired since shipment from factory. The products covered by this warranty must be manufactured after review date indicated at the bottom of page.
