Installation of the optional 460 CFMs second blower (part #: VENT460T+)

PR_I028/2023-08-08-EN
Revision : 10
Step 1: Remove the bottom right plate.
Push on one side of the plate to tilt it. Keep
twisting the plate until it comes apart.
Step 2: If it's not already done, remove the
access panel (B) on the back of the
appliance by unscrewing / untightening the
3 screws (A). Insert the 4 bolts (C) with their
screwing part oriented downward at the
designated location in the adjacent picture.
Put them inside the fan housing by passing
the hand through the access opening. Put

Adjustment of the fan speed

the second blower in
orientation compared to the first blower.
Screw the fan to the stove with the 4 lock
washers (D) and the 4 nuts (E) provided
with the fan kit. Connect the power supply
of the second blower to the electric outlet of
the first blower (G). Put back the access
hatch (B) in place
Adjustment of the fan
speed
It is possible to change the speed of the
blower(s) in between the high and the low
speed. The position of the switch(es) as
shown in the adjacent picture (J) should
correspond to the low speed configuration.
Note: There is no off position on the
switch(es)
the opposite
38
