Instruction Manual
Product # 10-000
STORE SERIES
SIRIUS – ANTARES - RIGEL
Certified and tested according to
CAN
/ULC S627-00
UL 1482-2011
2020 U.S. Environmental
Protection Agency's crib wood
emission standard
490, rue de l'Argon
Québec, CANADA G2N 2C9
Tél.: 418-849-8095
Fax : 418-849-0077
www.jaroby.com
April 28th, 2016
Printed in Canada
Advertisement
Table of Contents
Related Manuals for J. A. Roby SIRIUS
Summary of Contents for J. A. Roby SIRIUS
- Page 1 PLEASE READ CAREFULLY AND KEEP THIS MANUAL FOR FUTURE REFERENCE Instruction Manual Product # 10-000 STORE SERIES SIRIUS – ANTARES - RIGEL Certified and tested according to /ULC S627-00 UL 1482-2011 2020 U.S. Environmental Protection Agency's crib wood emission standard 490, rue de l'Argon Québec, CANADA G2N 2C9...
-
Page 2: Table Of Contents
Offset Installation ............18 Parts that can be replaced ..........29 Vertical Installation............19 J. A. ROBY LIMITED LIFE WARRANTY ........ 31 External combustion air source ..........20 Exterior Air Intake pipe ............20 Installation of Air Intake Pipe ......... 20 Air Inlet Obstruction ............ -
Page 3: Introduction
A good installation is very important for a safe and • Recommended wood length: 18 inches effective use of J. A. ROBY INC stove. In the doubt about the • Fuel Orientation: side to side. instruction step to install your appliance correctly, we suggest to •... -
Page 4: Nameplate
Nameplate April 28th, 2016... -
Page 5: Appliance Dimension
41.3" 105.0cm 33.0" 83.9cm 14.1" 11.0" 35.7cm 28.0cm Specifications Centauri, Polaris, Clearances to Option Vega, Antares Sirius, Rigel combustible material Wood Combustible Wood Wood Recommended 1800 Ft 1800 ft² 1800 Ft surface area Capacity 27 214 BTU/h 27 214 BTU/h... -
Page 6: Installation
Installation Canada: Fire Safety • 41 ¼ in (102.2 cm) • 47 in (119.38 cm) To provide reasonable fire safety, the following should be given • 3/8 in thickness (1 cm) serious consideration: Install at least one smoke detector on each floor United States •... -
Page 7: Minimums Clearances To Combustible Material
Minimums clearances to combustible material • With these reduced clearances, this appliance take a minimum For a 45° corner installation, or other corner of space where is installed. Whether in the living room or the installation, the minimum clearance between the dining room, the stove will complete your decorate by his stove and combustible material must be 8 inches. -
Page 8: Assembly Before Installation
Assembly before installation Fan and Snap disc box installation According to chosen option, to save more storage space and shipping. The stove leg couldn’t be assembled in the shop, you must assembly before install the stove. Legs installation Remove legs and bricks from combustion chamber to lighten the stove. -
Page 9: Warmer Stove Assembly (Optional)
WARNING: NEVER ROUTE POWER CORD UNDER OR IN FRONT OF THE APLIANCE Warmer stove Assembly (Optional). Now, you need to know which type of smoke pipe: smoke simple pipe or smoke double pipe. For the smoke simple pipe: It’s not necessary to remove the pre- cut metal part. - Page 10 Fix the top with the back and with the front too. Fix the left decorative panel side and finish to install the left chrome decoration Fix the right decorative panel side and finish to install the right chrome decoration. April 28th, 2016...
-
Page 11: Firebricks Installation
Put and fix the warmer with the 6 holes of each side to the cook stove. Floor firebricks installation Put 2 Bricks «A» near the wall and 2 bricks «D» in the center. Firebricks installation Side firebricks installation Put 4 bricks "A" and 2 brick "B" Angle firebricks installation Put «A»... -
Page 12: Firebricks Installation On The Pipes
Firebricks installation on the pipes Put the rockwool over the bricks and assume then the The firebricks must be put on the 3 pipes from the front of smoke exit way is not obstructed. combustion chamber. Bricks keep a maximum of heat inside the Put two half metal disk over the rockwool near the rear combustion chamber and help the air ratio to burn the most of deflector already in place. -
Page 13: General Stove Installation Steps
move the location of the stove while keeping the General stove installation steps minimum clearance or more to be sure. If you can’t move the stove and have to cut through a beam. Be Location considerations. sure to keep the structural integrity of your house by •... -
Page 14: Chimney Connector Installation
Chimney connector installation For direct vertical installation you will need. The chimney connector is a set of single wall or double wall flue pipes and elbow installed between the stove collar and the 1 adequate length for vertical section chimney collar. The single wall chimney connector is sold into 1 x adequate length of telescopic chimney any hardware store and are not homologated and certified. -
Page 15: Mobile Home Installation
Don’t forget to open the damper when operate your Mobile home installation stove so that the smoke will not enter the house. DANGER: DO NOT INSTALL IN BEDROOM. Always use certified parts for mobile home. Never use a substitute. WARNING: THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. -
Page 16: Chimney Installation, General Steps
• The chimney must be over 36 inches (91.4 Chimney installation, General steps cm) over the higher point into the roof Use only approved chimneys. The same size as the output opening. • collar. 6 inches in this case. The chimneys used must be tested The chimney must also be 24 inches over according to CAN/ULC S629 M87 in Canada and to UL 103 the highest point on the roof inside 10 ft (304... -
Page 17: Inside Masonry Chimney, Vertical Installation
Inside Masonry Chimney, Vertical Outside Vertical Installation Installation The wood appliance must be installed in accordance with the applicable local laws or the CAN/CSA-B365, NFPA211 (USA) The wood appliance must be installed in accordance with the norms. Follow the chimney manufacturer’s instructions to install applicable local laws or the CAN/CSA-B365, NFPA211 (USA) the chimney. -
Page 18: Offset Installation
Cathedral Vertical Installation Offset Installation The wood appliance must be installed in accordance with The wood appliance must be installed in accordance with the the applicable local laws or the CAN/CSA-B365, NFPA211 applicable local laws or the CAN/CSA-B365, NFPA211 (USA) (USA) norms. -
Page 19: Vertical Installation
Vertical Installation The wood appliance must be installed in accordance with the applicable local laws or the CAN/CSA-B365, NFPA211 (USA) norms. Follow the chimney manufacturer’s instructions to install the chimney. Always pass chimney between joists. If a joist need to be cut, referring to the National Building code to know how to do it safely to avoid structural integrity fail. -
Page 20: External Combustion Air Source
Before warming season, always inspect air inlet pipe to be sure External combustion air source nothing is obstructed the outside air inlet. In conventional designed house, natural ventilation is enough to operate the wood stove. In some new energy saving house, natural ventilation is not enough to good operation of your stove. -
Page 21: Operating Instructions
To ensure proper tubes orientation, a groove is cut at one end of tubes, and a corresponding emboss is cut into the hot air side channel. Operating Instructions Step to install a tube. • OPERATE ONLY WHEN DOOR IS CLOSED: Keeping the door open can over fire and do permanent damage Insert the tube into the round hole into the hot air side to the stove or a chimney fire. -
Page 22: First Fire
Once you have an ember fire, it’s time to add logs. Follow now the instruction section on how to keep a To keep the emission rate at the best value when you push the fire control knob to the lower burn rate, be sure to let the fire burn DO NOT OVER CHARGE THE STOVE OVER THE enough before closing the door to have the good inside UPPER BRICK ROW... -
Page 23: Wood Storage
(4) Materials containing plastic; ashes. Leave an ash bed approximately 1 inch deep on the firebox bottom to help maintain a hot charcoal bed. (5) Waste petroleum products, paints or paint thinners, or asphalt products; The ash have to be removed periodically every 2 or 3 days into heavy warming period. -
Page 24: Chimney Inspection
On some version of stove two screw is for retain the door. Chimney Inspection Cleaning up glass Wood moisture, wood species, the combustion quality, are some factors that can influence creosote buildup speed into To clean the glasses, J.A. Roby Inc. recommends using chimney and chimney connector. -
Page 25: Fiberglass Rope Replacement
Fiberglass rope replacement Use a ½ inches (12.7mm) braided fiberglass rope. It is possible to replace the braided fiberglass rope with the door on the stove, but if you want you can remove door. Fiberglass rope preparation Take the end of the fiberglass rope and push fiber inside to make a clean end. -
Page 26: Door Assembly
Appendix 1 Door assembly Square Door April 28th, 2016... -
Page 27: Arc Door
Arc Door April 28th, 2016... -
Page 28: Fans Electric Wiring Diagram
Appendix 2 Fans electric wiring diagram Therm-O-disk Box parts description April 28th, 2016... -
Page 29: Parts That Can Be Replaced
Appendix 3 Parts that can be replaced • Bricks • Doors glass • Spring Handle • Stove Door with handle • Fans • Flat fiber glass rope (around glass) • Round fiberglass rope • Ash Plug • Slotted Brick Washer To ordered parts call your stove seller representative. - Page 30 Appendix 4 Bricks dimension and quantity. April 28th, 2016...
-
Page 31: J. A. Roby Limited Life Warranty
WOOD BURNING STOVES & FIREPLACES J. A. ROBY’s warranty only applies to original buyer and is non-transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory. The products covered by this warranty must be manufactured after review date indicated at the bottom of page.
