Clearances To Combustibles Materials - J. A. Roby FORGERON CLASSIQUE Instruction Manual

Option
Combustible
Recommended
surface area
Capacity
Flue pipe
diameter
Minimal
chimney height
Exterior Height
Exterior Width
Exterior Depth
Door Opening
Interior Height
Interior Width
Interior Depth
Length log
tested
Chamber
combustion
depth
Volume tested
combustion
chamber
Weight

Clearances to combustibles materials

PR_I028/2023-08-08-EN
ROBY 2500 ATM 2500
Wood
1000 –
2 500 ft²
95 000 BTU 95 000 BTU
6 in
12 ft.
33-1/8 in
30 3/8 in
30-5/8 in
16-1/4 '' x 10- 16-1/4 '' x 10-
3/8 in
10-3/4 in
18 1/4 in
20 in
15 in
19 in
3
1.99 ft
380 lb
POSITION
Back (from the top)
Lateral (from the top)
Corner (from the top)
Front
Minimum Ceiling Height
Back of Flue Collar
Side of Flue Collar (lateral)
Side of flue collar (corner)
ATM 2500
PLUS PLUS
Wood Wood
1000 – 1000 –
2 500 ft² 2 500 ft²
95 000 BTU
6 in 6 in
12 ft. 12 ft.
33 1/8 in 51 1/4 in
29 7/8 in 29 7/8 in
30 5/8 in 31 7/8 in
16-1/4 '' x 10-
3/8 in 3/8 in
10-3/4 in 10-3/4 in
18 1/4 in 18 1/4 in
20 in 20 in
15 in 15 in
19 in 19 in
3 3
1.99 ft 1.99 ft
380 lb 510 lb
DISTANCE
16 1/2 in
12 in
10 in
18 in
84 in
18 in
22-1/2 in
20 in
Revision : 10
2500 F ROBY 2500
CUISINIERE
Wood Wood
1000 – 1000 –
2 500 ft² 2 500 ft²
95 000 BTU 95 000 BTU
6 in 6 in
12 ft. 12 ft.
51 3/8 in 54 1/8 in
30 3/8 in 30 3/8 in
30 5/8 in 30 5/8 in
16-1/4 '' x 10- 16-1/4 '' x 10-
3/8 in 3/8 in
10-3/4 in 10-3/4 in
18 1/4 in 18 1/4 in
20 in 20 in
15 in 15 in
19 in 19 in
3
1.99 ft 1,99 ft
490 lb 440 lb
3
12
