General stove installation steps

1) Read the entire installation manual before installing
and using your stove.
2) Choose a place to install your appliance. Read the
sections about dimensions of floor protection panel,
localisation of stove over the floor protection panel, and
clearance to combustible materials. Once you have
decided where to install the stove, mark the center of
chimney on the floor.
o
To make sure the vertical center of the
chimney, use a plumb line to mark on the
floor.
3) Verify if it is possible to pass chimney without
damaging the structure of your house. You might have
to move the location of the stove while keeping the
minimum clearance. If you have to cut a joist, make
sure to respect the building code in effect to keep the
structural integrity of your house.
Note: This appliance has to be connected to:
•
A type HT chimney of 6 inch diameter (15.24 cm)
listed to ULC-S629.
•
A conforming masonry chimney of 6-inch
diameter (15.24cm) with qualified internal lining.
4) Install the chimney following the manufacturer
instructions.
5) Put the stove on the floor aligned vertically with the
center of chimney and trace the 4 sides of the stove
vertically on the floor. Please remove the stove.
PR_I028/2023-08-08-EN
6) Mark the dimensions of protection panel on the floor.
The edge clearance of the sides and the back is
8 inches (20.3 cm). At the front, it must be 18 inches
(45 cm) in Canada, measured from the front door.
7) Install the floor protection panel according to the mark.
(It must be non-combustible)
8) Put the stove on the protection floor panel. Respect the
edge clearance that you have set at step 6 and the
centre of the chimney as well. We recommend to fix the
stove to the floor with bolt in the slots in the stove legs
made for this purpose. If you have a pedestal, use the
holes made for this purpose.
9) If you have an outside air inlet, you must use 4 inch
(10.16 cm) flexible aluminum pipe. The pipe must be
sealed with thermal resistant sealant.
10) Install the chimney connector from the stove. The pipe
must be attached with at least 3 screws, to the collars
of the stove and the chimney, also each joint of
connection.
Note:
•
•
•
.
Revision : 10
The single wall chimney connector must be 6-inch
diameter (15,25 cm) and have a minimum
thickness of 24 gauge (0.025 inches 0.64 mm).
Do not use galvanised steel chimney connector.
For installation in a mobile home consult the
section on mobile homes
