Tumbling
To create a tumbling motion, load the tubes and mount the rotisserie
so the tubes are held in a vertical position.
Then, rest the unit on its end making sure that it is supported by the
black rubber side legs. The unit can be rested on either end. Setting
the unit on the end with the power switch will create more vigorous
tumbling motion than when it is rested on the opposite end.
8.0 Cleaning and Maintenance
No routine maintenance or lubrication is required. Keeping the rotator clean will the help to maintain it in proper operating condition.
8.1 Cleaning
The outside housing can be cleaned with a soft, damp cloth when needed.
NOTE: Before cleaning the rotator, always unplug the power cord. Do not use any aggressive or abrasive cleaners (acetone, nitro,
polish, etc.). This may permanently damage the rotator finish.
9.0 Troubleshooting Guide
Be sure to disconnect the rotator from the main power source immediately in case of any signs of malfunction.
Problem
Rotator does not start
Should you have a question about the operation of the Labnet Mini LabRoller™ Rotator or if service is required, contact Corning
Customer Service. Do not send in a unit for service without first calling to obtain a repair authorization number. Should the unit
require return for service, it should be properly packed to avoid damage. Any damage resulting from improper packaging shall be the
responsibility of the user.
10.0 Accessories
Cat. No.
Description
H5500-02
Rotisserie for 36 x 1.5/2.0 mL microcentrifuge tubes
H5500-15
Rotisserie for 10 x 15 mL tubes or 12 x 5/7 mL tubes
H5500-50
Rotisserie for 6 x 50 mL tubes
Mixing Plates
Any of the rotisseries can be used for mixing in microplates.
Remove the rotisserie rod if it is installed.
Seal the microplates completely to avoid leakage. Make
sure the microplate lines up with the locking dimples.
Fasten the plate (or plates) with rubber bands or small
bungee cords (not supplied with the unit). Maximum of
two deep well plates can be mixed at a time. For all other
types of motion, two plates should be placed on the
rotisserie for proper balance.
Solution
Check the power connection.
Check if the rotisserie is properly inserted into the drive mechanism.
Call for service.
Instruction Manual
|
3
