ECM pmCAN Module Instruction Manual page 31

The pmCAN Kit consists of:
Description
1. pmCAN Control Module
2. PM Sensor (tailpipe application) or
PM Sensor (diesel engine-out application)
3. PM Sensor Cable, (2m)
4. Flexi-Eurofast Cable, (0.3m)
5. Eurofast "T"
6. Eurofast Terminating Resistor
7. Eurofast 12mm Cable, (2m)
8. DC Power Cable, DB9F, Banana
9. Sensor Boss & Plug, SS, (18mm x 1.5mm)
10. Manuals and Configuration Software CD
Optional Components:
1. AC/DC Power Supply, Universal 24VDC @ 4.2A
(requires P/N 11-17 Deutsch DTM3M to DB9F Cable)
2. Kvaser Leaf Light CAN Adapter
3. PM Sensor Cable (3m)
Note: pmCAN has been approved for use with no
sensor cable, a 2m sensor cable, a 3m sensor
cable, and any combination of cable lengths
up to 6m. Tie the sensor cable(s) down since
cable wiggling will generate noise in the PM
and PN signals due to the triboelectric effect.
4. PM Sensor Cleaning Kit
5. Spare PM Sensor Gasket
