ECM pmCAN Module Instruction Manual page 22

Name
C1R 16 bit A/D Calibration (Bits)
C2R 16 bit A/D Calibration (Bits)
ERCD ECM CANOpen Error Code (unsigned integer)
ERFL Module Error Flags (unsigned long format)
ILK Sensor Leakage Current (0-40 µA)
IST Sensor Current (0-1000 nA)
ITP Transformer Primary Current (0-225 mA)
ITPC Calculated Transformer Primary Current (0-225 mA)
Delta Table Modified Particulate Matter Mass Density (mg/m3),
PM
PM = PMR + Delta Table for PM. Use this parameter for PM.
PMR Factory-Calibration Particulate Matter Mass Density (mg/m3)
Delta Table Modified Particulate Matter Number Density (M/cc),
PN
PN = PNR + Delta Table for PN. Use this parameter for PN.
PNR Factory-Calibration Particulate Matter Number Density (M/cc)
TPCB Temperature of the Module Circuit Board (deg C)
VHV Actual High Voltage Electrode Voltage (0-2000 V)
VHVC High Voltage Electrode Voltage Command (0-2000 V)
VILK Voltage output of Sensor Leakage Current Circuit (0-5000 mV)
VIST Current Measurement Voltage (0-5000 mV)
VSW Supply Voltage at pmCAN Module (0-40 V)
16
Parameter Description
Table 2: pmCAN Parameter List
