Configuring a Module

Normally, you will be configuring a module to be used in stand-alone mode. Stand-alone
mode is used when the modules are connected to a CAN bus that goes directly to a data
acquisition or control system. In stand-alone mode, a module's configuration is performed by
selecting one of the tasks in the "Task" field. When a module is connected to a NOx 5210,
Lambda 5220, EGR 5230, NH 5250, or miniSOOT 5260 Analyzer, it must be in EIB mode.
3
In EIB mode, most of these tasks are performed using the analyzer. Appendix B describes
how to configure a module to operate in one mode or the other.
The following assumes that the module is to be used in stand-alone mode. The tasks
available for pmCAN modules are listed in Table 1.
