ECM pmCAN Module Instruction Manual page 23

ECM Error Code LED Action
(hex) (R=red, G=green)
0x00 G On
0x01 Flash G @ 10hz
0x02 G,G&R,R @ 2s
0x13 R On
0x14 Flash R 1x @ 2s
0x15 Flash R 1x @ 2s
0x41 Flash R 4x @ 2s
0x42 Flash R 4x @ 2s
0x52 Flash R 5x @ 2s
0x61 Flash R 6x @ 2s
0x62 Flash R 6x @ 2s
0xA1
0xB1
0xB2
0xB3
0xB4
0xB5
0xB6
0xB7
0xB8
0xB9
0xBA
0xFF G&R On
Notes:
1. "G,G&R,R @ 2s" means Green LED Flashes, then Red and Green LEDs flash together,
then just Red LED. This pattern repeats every 2 seconds.
2. "Flash R 4x @ 2s" means Red LED Flashes 4x and this is repeated every 2 seconds.
3. If an error from 0x00 to 0x62 is present, PM, PN, PMR, and PNR are set to -1.
All OK
Start-Up
Power ON Reset/Init Hardware
High Voltage Off
No Sensor Detected
Water in Sensor
ITP Too High
ITP Too Low
VHVC - VHV > 100V for 5s
ILK Fault
IST Fault
Invalid Software State
CAN Overrun
CAN Passive Mode
CAN Heartbeat Error
CAN Recover Bus Off
CAN Tx CAN ID Collision
Serial Overrun
CAN Overrun LSS
CAN Overrun SDO
CAN Overrun Rx
CAN Overrun ECT5
Module Powering Down Within 500ms
Table 3: pmCAN Error Codes List
Description of Error
17
