AUTO GYRO Cavalon Maintenance Manual page 222

36-21-00 8-1 REPLACEMENT: FILTER/DRYER
GENERAL, REFERENCES AND REQUIREMENTS
Task may only be performed by an organization or individual trained and entitled to carry out 'Professional
Maintenance'!
Secure gyroplane against unauthorized or unintended operation!
SPECIAL TOOLS AND CONSUMABLE MATERIALS
None
PRECAUTIONS AND SAFETY MEASURES
PROCEDURES
1 Gain access to the pneumatic box situated behind the center cockpit panel.
2 Unscrew inlet and outlet connection of the dryer-filter and discard old seal ring (compressor side only).
3 Replace filter/dryer with new one and make sure cartridge is tightened safely to rear wall. Install new seal.
4 Re-connect and tighten inlet and outlet connection with moderate torque.
ILLUSTRATIONS
AMM-CV-915iS/916iS-EN-
E-2023-12
Aircraft
Maintenance Manual
Compressor
Dryer Filter
Fig 1 – Pn Box, Compressor & Dryer Filter
Part E - 36-21-00 8-1
AutoGyro
Cavalon 915 iS / 916 iS
Pneumatic Box
Page 3 of 3
