AUTO GYRO Cavalon Maintenance Manual page 166

1 2
B
C
D
7 x timer contact
(male)
E
F
G
1 2
3 4
B
Schirm unter
Kontakt
50mm
3 4
5 6
B
A
Schirm auflegen
1300 mm
Co-Sign 1:
PIN Kabelfarbe
9 WH 0.35²
20 BK 0.5²
This drawing may not be used in any from without ourexplicit
21 RD 0.5²
permission. Nor may it be shown publically, by third party or
for competitve purposes. Changes to the design, composition
31 WH/BU 0.35²
or processing require prior authorisation from AutoGyro.
38 BK 0.5²
41 BK 0.5²
42 RD 0.5²
52 BN 0.35²
59 BK 0.5²
61 OG 0.5²
RotorSport UK Ltd
62 OG 0.5²
Unrivalled Sport Gyroplanes
5 6
7 8
Garmin G3X - GTX 35R installation kit
(46171)
Please preinstall the rack mount
M.Sc. Harald Stindl
A000 New
2020.11.19 09:41:07 +01'00'
A001
Co-Sign 2:
Rev CMS
Modification
Name (engl.) / Name (ger.) / Part Number
Garmin GTX 35R
Date
Name
installation kit / Einbausatz
Drawing 01.10.2020 H. Stindl
Pro.Nr.
46111
A3
Format:
Sheet:
1 of 1
7 8
9
B
C
D
E
F
22.02.2019 H.STINDL
22.02.2019 H.STINDL
06.10.2020 H.STINDL
Date Name
G
Revision
A001
9
