OTHER FUNCTIONS

Screen Capture function

You can capture the receiver display onto a microSD
card. Most of the screens used in this manual are
captured using this function.
However, some displays cannot be captured.

DSetting the Screen Capture function

[MENU] > SET > Function >
Screen Capture [PWR] Key
1. Push [MENU].
2. Select "Function" in the "SET" menu.
3. Select "Screen Capture [PWR] Key."
4. Select "ON."
L To exit the MENU screen, push [MENU].

DCapturing a screen

1. Display the desired screen to capture.
2. Push [ ] to capture the screen.
• The captured screen is saved onto the microSD card.
[ ]

DViewing the captured screen

[MENU] > SET > SD Card > Screen Capture View
1. Push [MENU].
2. Select "SD Card" in the "SET" menu.
3. Select "Screen Capture View."
• The capture list is displayed.
• The latest screen capture is at the bottom of the list.
4. Select the desired screen capture to display it.
• The screen capture is displayed.
L While a screen capture is displayed, you can scroll
through all the screen captures by rotating [DIAL].
L To exit the MENU screen, push [MENU].
Checking the file information and deleting a file:
1. Select the screen capture that you want to view
or delete.
L DO NOT push [ENT].
2. Push [QUICK].
3. Select an item from "File Information," "Delete,"
and "Delete All."
• File Information: Displays the file name, size,
• Delete:
• Delete All:
8-6
and date of the selected screen
capture.
Deletes the selected file.
Deletes all files.
