Playing Back The Recorded Audio On A - Icom IC-R15 Advanced Manual

6
RECORDER FUNCTION
Playing back the recorded audio on a PC
You can play back the recorded audio on your PC�
L The recorded information (frequency, date, and so on) is
not displayed�
L Windows 11 is used for these instructions�
Example: Connecting the receiver and PC with a
USB cable, then playing the audio file on
the microSD card on your PC�
NOTE: Insert the microSD card that contains the
recorded audio file into the receiver's slot�
[MENU] > SET > Function > USB Connect
1� Connect the receiver and PC with a USB cable�
Supplied USB cable
(Type-C/Type-A)
To the [USB]
2� Push [MENU].
3� Select "Function" in the "SET" menu�
4� Select "USB Connect�"
5� Select "SD Card Mode�"
• A confirmation dialog is displayed�
6� Select "YES�"
• The receiver is connected to the PC in the SD Card
mode, and the SD card folder is displayed on the PC
screen�
• The microSD card are directly accessed from the PC�
7� Double-click the 'IC-R15' folder�
8� Double-click the 'Voice' folder�
To a USB port PC
Double-Click
Double-Click
9� Double-click the folder that contains the audio file
to play it back� (Example: "20231130")
10� Double-click the file to play it back�
(Example: "202301130_120013A�wav")
L See the instruction manual of your player for
operation details�
L The audio file may not play back, depending on the
player�
6-7
Double-Click
Double-Click
