4. When you are ready, begin driving on the metered mile. You will notice that the reading will
start counting up. The odometer will begin to display the incoming pulse count. Drive the
vehicle through the measured mile (speed is not important, only the distance traveled).
5. At the end of the mile, stop and press the push-button again. The odometer will now display
the new number of speedometer pulses that were registered over the distance. The
odometer will continue to display the pulse reading for a few seconds. Once it reverts to the
default mode, you have successfully calibrated your speedometer.
Warning: If, while in 'CAL' mode, you do not move the vehicle and press the button
again, the microprocessor will NOT have received any data and the unit will display
'Err' and will revert to the factory settings. At a minimum, drive some distance and
return to the start if necessary. If you miss stopping the display at 'CAL', simply repeat
the steps.
Trip Distance
A single tap of the recall button will activate the trip meter in the odometer display. A decimal
point will appear which will indicate that you are in trip meter mode. Holding the recall button will
clear out the trip distance. To return to the default odometer display, tap the recall button again.
The decimal point will disappear, indicating that you are back in the default odometer display.
Setting the Odometer
While scrolling through 'CAL' mode you will see 'ODO' appear. This will allow you to enter the
vehicle's actual mileage. Press the trip button again at this point and you will enter the odometer
set up mode. Press quickly to change the number of the digit on the right. Press and hold to
advance to the next digit. Do this for all 5 digits. For Example: To enter the mileage reading
23456 into the odometer, at the 'ODO' prompt, tap the small black button (quickly) two times, until
the number 2 is displayed. Then press and hold the button until the numbers 20 are displayed. Tap
the button 3 times until 23 is displayed. Press and hold the button until 230 is displayed, then
continue in this manner until 23456 is displayed. The speedometer will advance to the home screen,
five seconds after the last number is entered.
Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
1. Before each run, your car must be at a complete stop at the starting position. Press and hold
the push-button as it cycles through the performance data. At the end, the odometer will
reset and all performance data will be cleared. This will not affect your stored calibration
value or the odometer reading.
2. Press the push-button until 'HI-SP' is displayed. The gauge will automatically cycle through
the performance data.
3. Start the run, pass, session, etc., as mentioned above.
4. When finished, repeat Step 2 to view the data gathered from the run. While stopped, you
can view this data as often as you wish. However, once it finishes scrolling one time, the
memory is ready to record new data and will begin recording again once the vehicle starts
to move. The highest speed measured over multiple runs will be retained in memory.
