1.3 LCD Specifications

 Display type: 7" LED backlight panel
 Max. resolution: 800 x 480
 Colors: 262 K
 Pixel Pitch (um): 192.6 x 179
 View Angle: 140°/160°
Luminance: 450 cd/m

Temperature: 0 ~ 50° C

 VR control: Brightness
Note! The color LCD display installed in the UTC-307 is high-quality and reli-
able. However, it may contain a few defective pixels which do not
always illuminate. With current technology, it is impossible to completely
eliminate defective pixels. Advantech is actively working to improve this
technology.

1.4 Dimensions

185
75X75 VESA M4 SCREW hole 3mm depth
75
Note! Fixed VESA screw: M4, screw depth: 4.0mm (max.).
2
32.25
Figure 1.1 Dimensions of UTC-307
3
185
75X75 VESA M4 SCREW hole 3mm depth
75
