Installer Menu
1 Language
2 Date/time
3 Machine orientation
4 Normal Mode
6 Bypass settings
Installer Menu
1 Language
2 Date/time
3 Machine orientation
4 Normal Mode
6 Bypass settings
Installer Menu
1 Language
2 Date/time
3 Machine orientation
4 Normal Mode
6 Bypass settings
Installer Menu
1 Language
2 Date/time
3 Machine orientation
4 Normal Mode
6 Bypass settings
Installer Menu
1 Language
2 Date/time
3 Machine orientation
4 Normal Mode
6 Bypass settings
It allows to select one language among English, Italiano, Deutsch, Čeština, Slovenský, Français,
Español, Polish, 中国, Magyar and Русский.
Press OK to enter.
Select the language using  or .
Press OK to select.
Factory setting (DEFAULT): English.
It allows to set the date and the time.
Press OK to enter.
Select the item using  or  and press OK.
Set the date and the time using  or and press OK to confirm.
Press ESC to go back to the previous menu.
It allows to select the orientation of the duct connections from and to outside (LEFT or RIGHT
hand configuration as per § 3.3).
Press OK to enter.
Choose "Left" or "Right" using  or .
Press OK to select.
Factory setting (DEFAULT): Left.
It allows to select one operation among Normal Mode 3V, Slave or Constant Pressure.
Press OK to enter.
Choose the operation mode using  or . Press OK to select.
Factory setting (DEFAULT): 3V
3V Mode
To adjust the speeds, refer to the paragraph "10 Speed setting" in the Installer Menu.
Slave Mode
It allows to control the speed by means of the 0-10V analogic input: any other operation logic
is ignored.
If the Slave mode is activated, the icon
Constant Pressure Mode
Currently not available.
It allows to set the Bypass operation parameters.
Press OK to enter.
Select the submenu item using  or  and press OK to confirm:
1 Desired Temperature: it is the ambient temperature desired by the user.
2 Tmax Free Heating: it is the maximum allowed outside temperature for free heating operation.
3 Tmin Free Cooling: it is the minimum allowed outside temperature for free cooling operation.
The setting ranges are:
Desired Temperature: 15°C ÷ 30°C. Factory setting (DEFAULT): 23°C.
Tmax Free Heating: 25°C ÷ 30°C. Factory setting (DEFAULT): 28°C.
Tmin Free Cooling: 15°C ÷ 20°C. Factory setting (DEFAULT): 18°C.
Increase/decrease the temperature using  or .
Press OK to select.
Press ESC to go back to the previous menu.
If the Bypass functionality is activated, the icon
and the word Slave are displayed.
is displayed.
