aerauliqa QR280E Instructions For Installation, Use And Maintenance Manual page 41

QR590E
600
550
500
450
400
350
300
250
200
150
B
100
50
A
0
0 50 100 150
100
90
80
70
60
50
40
30
Thermical efficiency curve
Curva di efficienza termica
20
Hygrometric efficiency curve Curva di efficienza igrometrica
10
0
0 50 100 150
E
D
C
200 250 300 350
Portata d'aria - m 3 /h
200 250 300 350
Airflow - m /h
3
G
F
400 450 500 550
400 450 500 550
Curve Speed %
A (min) 21
B 37
C 54
D 58
E 67
F 81
G (max) 100
Fig. 6.d Intake curve according to Reg.
1253/2014 (ErP). Product tested
without filter F7.
600
Fig. 6.e Data of the enthalpic heat
exchanger.
Test conditions:
Indoor air 25°C 50% RH;
600
External air 5°C 70% RH.
W m /h
3
max max
11 108
38 249
117 396
146 432
234 516
305 555
343 595
41
