ORDERING INFORMATIONS:

The ordering part number is formed by a valid combination of the following:
HD67717 – xxx – x x
Connectors Type
1: Removable 5mm Screw Terminal
2: Fixed 5mm Screw Terminal
Enclosure Type
A: 1M, 35mm DIN Rail mounting
B: 4M, 35mm DIN Rail mounting
BACnet type
IP: BACnet/IP
MSTP: BACnet MSTP
Device Family
HD67717: BACnet Master / CAN - Converter
Order Code: HD67717-IP-A1
Order Code: HD67717-MSTP-A1
Order Code: HD67717-MSTP-B2
ACCESSORIES:
Order Code: AC34001 -
Order Code: AC34002 -
ADFweb.com S.r.l.
- BACnet/IP Master / CAN - Converter
- BACnet MS/TP Master / CAN - Converter
- BACnet MS/TP Master / CAN - Converter
35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V AC
35mm Rail DIN - Power Supply 110V AC 50/60Hz – 12 V AC
User Manual BACnet Master / CAN
Document code: MN67717_ENG Revision 1.001 Page 32 of 34
