CHARACTERISTICS:
The HD67717-IP-A1 and HD67717-MSTP-A1/B2 are BACnet Master / CAN - Converters.
They have the following characteristics:
Up to 512 BACnet objects in reading and 512 objects in writing;
Up to 500 CAN frames in reading and 500 CAN frames in writing;
Triple isolation between BACnet - Power Supply, BACnet - CAN, Power Supply - CAN.
Two-directional information between BACnet and CAN;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67717 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of CAN line;
Define CAN frames that the converter accepts;
Define CAN frames that the converter sends;
Define the BACnet data that the converter reads;
Define the BACnet data that the converter writes;
Update the device.
