ORDERING INFORMATIONS:

The ordering part number is formed by a valid combination of the following:
HD67712 – xxx – x – A1
Order Code: HD67712-IP-2-A1
Order Code: HD67712-IP-4-A1
Order Code: HD67712-MSTP-2-A1
Order Code: HD67712-MSTP-4-A1
ACCESSORIES:
Order Code: AC34011 -
Order Code: AC34012 -
ADFweb.com S.r.l.
Connectors Type
1: Removable 5mm Screw Terminal
2: Fixed 5mm Screw Terminal
Enclosure Type
A: 1M, 35mm DIN Rail mounting
B: 4M, 35mm DIN Rail mounting
Modbus port
2: RS232
4: RS485
BACnet type
IP: BACnet/IP
MSTP: BACnet MSTP
Device Family
HD67712: BACnet Master / Modbus Slave - Converter
- BACnet/IP Master / Modbus Slave – Converter (Modbus on RS232)
- BACnet/IP Master / Modbus Slave - Converter (Modbus on RS485)
- BACnet MSTP Master / Modbus Slave - Converter (Modbus on RS232)
- BACnet MSTP Master / Modbus Slave - Converter (Modbus on RS485)
35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC
35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 24 V DC
User Manual BACnet Master / Modbus Slave
Document code: MN67712_ENG Revision 1.200 Page 35 of 37
