In the field "Max Error" the number of consecutive errors that the Master waits before discard the row from the cycle of requests is
defined;
In the field "Position" it is possible to select the position/byte where taking the data from the internal array is defined;
The field "Start Bit" is used for the Binary BACnet objects. It is possible to select the bit in the byte from which taking the data;
In the field "Mnemonic" a description of the data inserted in the row is defined.
