Mecmesin OmniTest 0.5 User Manual page 3

2
Introduction
OmniTest™ and VectorPro™ are both registered trademarks of Mecmesin Ltd. OmniTest™ and VectorPro™
This reference manual covers the operation of Mk1 and Mk2 OmniTest 0.5, OmniTest 1.0, OmniTest 2.5,
OmniTest 5 and OmniTest 7.5 OmniTest 5 OmniTest 7.5 force test systems, intended for use with Mecmesin enhanced load sensors,
extensometer devices and other Mecmesin accessories. This manual may also refer to these devices as 'Single
Column'. Column
Force sensors used by the OmniTest test stands are called ' E nhanced Load Sensors
the term 'ELS ELS' in this manual.
The Mk1 OmniTest versions may also be referred to as "Blue" and Mk2 OmniTest versions as
"Black".
Operation of additional accessories and associated software is covered in the separate user manuals
that are available from the help web site:
machine models in the main, but where reference to a particular model is required it will explicitly
state detail of that variant.
The following manuals may aid you in the use of your test stand: The following manuals may aid you in the use of your test stand:
Guide to Safe Use of Mains Powered Test Systems (431-398) Guide to Safe Use of Mains Powered Test Systems (431-398)
Covers the initial setup and installation of VectorPro, as well as the basics of the software
functionality and user manuals. Further guidance relating to other aspects of VectorPro can
be accessed through this user manual.
Mecmesin Long Travel Extensometer Installation Guide (431-969) Mecmesin Long Travel Extensometer Installation Guide (431-969)
Runs through the installation and operation of Long Travel Extensometers in conjunction with
OmniTest systems.
VectorPro™ User Manual - Introduction and Initial Setup (431-955) VectorPro™ User Manual - Introduction and Initial Setup (431-955)
Covers the initial setup and installation of VectorPro, as well as the basics of the software
functionality and user manuals. Further guidance relating to other aspects of VectorPro can be
accessed through this user manual.
It is essential that you familiarise yourself with the contents of this Manual and the separate
To Safe Use Of Mecmesin Mains Powered Test Systems To Safe Use Of Mecmesin Mains Powered Test Systems
operate your OmniTest test stand.
2.1
User Manual Icons
Throughout this manual, the icons shown below are used to identify important health and safety information as
well as additional installation/operation guidance. Do not proceed until each individual message is read and
thoroughly understood.
2.1.1
Warning
The warning warning icon highlights a situation or condition that may lead to possible personal injury or
damage to the associated equipment.
OmniTest 0.5, OmniTest 1.0, OmniTest 2.5,
Enhanced Load Sensors ' and they are abbreviated to
help.mecmesin.com. This manual will refer to both help.mecmesin.com
(part no. 431-398) 431-398) before attempting to
Single
A Guide A Guide
3
